Home > Products > Hot Selling Condenser > Fruit Display and Fridge Air Cooled Condenser
Fruit Display and Fridge Air Cooled Condenser
- SHANGHAI/NINGBO
- T/T Money Gram Credit Card
You May Like
-
Refrigerator Showcase Assembly And Parts Condenser
-
Commmercial Display Fridge Wire Condenser With Rubber Plug
-
Copper Tube Aluminum Fin Condenser For Fridge
-
Stainless Steel Wire Condenser For Commercial Bar Fridge
-
Fridge Parts 14U Wire Tube Condenser With Rohs Certificates
-
Supermarket Display Refrigerator Condenser
Product Details
| Type | Condenser | Place of Origin | Hubei, China | |
| Brand Name | TJ | Model Number | 28 | |
| Certification | ROHS |
Packing in plastic bags or in standard carton box
Product Description
Specifications
ISO9001, ROHS ,LFGB approvedSuperior supplier of Midea
30 years professional manufacturing condenser/evaporator
experience
ISO9001, ROHS ,LFGB approved
Superior supplier of Midea
30 years professional manufacturing condenser/evaporator
experience
Fruit display fridge air cooled condenser
Specification:
Raw material | Rolling welded steel tube : Out Diameter 8mm , Wall Thickness 0.6-0.71mm; |
Technical Ability | 1)The distance of steel wire ≥6mm; 2)Produce according to the drawing or sample supplied by clients; |
performance | 1)Surface treated with powder painting or dip coating to prevent the corrosion 2)Inner cleanness can meet the requirement of R134a &CFC cooling system; 3)Can satisfy the cooling capability requirements; 4)Producing Capacity: 3000 pieces/Day; |
Production capacity: | Relying on the advanced imported equipment and the unremitting effort of all the staff of the company, the production capacity has reached 3.5 million sets or pieces a year. |
R134a cooling system tube pamameters
Residual Moisture | ≤20 mg/m2 |
Residual Impurity | ≤30 mg/m2 |
Residual Mineral Oil | ≤7 mg/m2 |
Residual Chlorine | ≤0.3 mg/m2 |
Residual Paraffin | ≤0.2 mg/m2 |
coating parameters
Coating Thickness | Thickness of coating 30-100um |
Harness of Coating | ≥2H |
Impact of Coating | 50 kg/cm impact, no crack |
Adhesion of coating | ≥two grade |
Flexibility of Coating | Around R=3D bend 180, no crack or no fall off |
Color tolerance of Power Painting | E≤1.5 |
More products catalog for your reference:
Wire tube condenser | A.Flat type: 1. 6U/7U/8U/11U/12U/14U wire tube condenser 2. 17rows,21rows,23rows wire tube condenser |
B. Monolayer flat wire tube condenser | |
C. Double layer flat wire tube condenser | |
D. Winding type wire tube condenser | |
Wire tube evaporator | A. Two layer/sheet wire tube condenser |
B.Three layer wire tube condenser | |
C.Four layer wire tube condenser | |
D.Seven layer wire tube condenser | |
Fin Aluminum evaporator | / |
Fin Aluminum Condenser | / |
Tube plate evaporator | / |
Professional manufacturer for condenser and evaporator:
Professional factory: | Specialized in the production of refrigerator condenser and evaporator in 1984 . We have about 30 years experience in development and practical experience. |
Technology: | It owns over 50 sets of equipment imported from Italy and Switzerland and more than 10 sets of specialized testing and detecting equipment. |
OEM: | operate with Aucma, Little Swan, Midea, LG, TCL and other well-know domestic and foreign enterprises. |
Advantages: | Freon-free, high efficiency and energy saving. |




CANTACT:
TEL:+86-716-8390039
MOB:+86-15927721264
SKYPE:Joany1991
WEB:http://jztaijia.en.china.cn/
Samples and drawings are welcome!
.
Company Profile
Jingzhou Taijia Refrigeration Equipment Co., Ltd. is a manufacturer established in 1984 and specialized in the research, development and production of wire tube condenser, wire tube evaporator, finned evaporator ,finned condenser and tube plate evaporator for refrigerator,freezer . We are located in Jingzhou, with convenient transportation access. All of our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world. If you are interested in any of our products or would like to discuss a custom order, please feel free to contact us. We are looking forward to forming successful business relationships with new clients around the world in the near future.
