Home > Consumer Electronics > Refrigerator, Freezer & Parts > Freezer & Refrigerator Parts > Folding Wire Tube Condenser for Freezer

Folding Wire Tube Condenser for Freezer

US$ 3 - 5 MOQ: 100 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Hubei, China

Brand Name:

Model Number:

BD169

Contact Supplier Request Quote Chat Now

Jingzhou Taijia Refrigeration Equipment Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI/NINGBO/JINGZHOU

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Hubei, China

Brand Name TJ

Model Number BD169

Specifications

30 years professional manufacturing condenser/evaporator experience
ROHS,ISO9001.LFGB certificate
Good supplier for Midea

1.30 years professional manufacturing condenser/evaporator experience

2.ROHS,ISO9001.LFGB certificate

3.Good supplier for Midea Refrigerator

4.OEM

5.No frost, freon-free

Folding wire tube condenser freezer

Specifications:
High heat exchange efficiency
Wire On Tube Evaporator for Fridge
Energy saving, Corrosion-resistant
Environmental protection,
Raw Material	1)Rolling welded steel tube : Out Diameter 8mm , Wall Thickness 0.6-0.71mm;
	2)Low carbon steel wire O.D.1.4-1.5mm
	3)Bracket:Steel Plate (SPCC),thickness 0.6-0.8mm
Structure	1)Evaporator for single temperature control system (single capillary evaporator)
	2)Evaporator for double temperature control system (double capillary evaporator)
	3)Evaporator for three way temperture control system (three capillary evaporator)
Key Process	Tube bending, Tube welding, Mono shelf assemble, Assembly welding, Leakage testing
	Coating, Inspection, Package
Technical Ability	1)The distance of steel wire ≥6mm
	2)Produce according to the drawing or sample supplied by clients
Performance	1)Surface treated with powder painting or dip coating to prevent the corrosion1)
	2)Inner cleanness can meet the requirement of R134a &CFC cooling system
	3)Can satisfy the cooling capability requirements
	4)Producing Capacity: 3000 piece/Day
R134a Cooling System Tube Inside Standards
Residual Moisture		≤20 mg/m²
Residual Impurity		≤30 mg/m²
Residual Mineral Oil		≤7 mg/m²
Residual Chlorine		≤0.3 mg/m²
Residual Paraffin		≤0.2 mg/m²
Specification of Coating
Coating Thickness		Thickness of coating 30-100um
Harness of Coating		≥2H
Impact of Coating		50 cmkg/cm impact, no crack
Adhesion of coating		≥ two grade
Flexbility of Coating		Around R=3D bend 180°,no crack or no fall off
Color tolerance of Power Painting		E ≤ 1.5

SELLER RECOMMEND HOT SELLING PRODUCTS:

3-LAYER WIRE TUBE EVAPORATOR

4-LYAER WIRE TUBE CONDENSER

3-LAYER WIRE EVAPORATOR COIL

Why choose us: Taijia--Professional manufacturer for evaporator and condenser

Professional factory:	Specialized in the production of refrigerator condenser and evaporator in 1984 .We have about 30 years experience in development and practical experience.
Technology:	It owns over 50 sets of equipment imported from Italy & Switzerland and more than 10 sets of specialized testing and detecting equipment.
OEM:	operate with Aucma, Little Swan, Midea, LG, TCL and other well-know domestic and foreign enterprises.
Advantages:	Freon-free, high efficiency and energy saving.


Production capacity:	Relying on the advanced equipments and our staff effort, the production capacity has reached 3.5 million sets a year.

Taijia-----Your best choice!

We can supply and produce new design products according to your requirment, and we also can help you to design new samples. If you are interested in our products, PLS cantact me and we will quote you the details for your referrence.
