Home > Electrical & Electronics > Electronic Tube & Transistor > Rectifier Diode > E6-XD . E6-XDF. E6-XDJ Push Button Switch With Indicator
E6-XD . E6-XDF. E6-XDJ Push Button Switch With Indicator
Negotiable
MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
KND
Model Number:
E6-XD . E6-XDF. E6-XDJ
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Led Indicator Lamp 220v 110v 24v 6.3v XD106NegotiableMOQ: 10 Pieces -
Indicator Led Lamp 220v 110v 24v Red and Green 10MDX-11CNegotiableMOQ: 10 Pieces
-
Latest Led 22mm Indicator Lamp 110vNegotiableMOQ: 10 Pieces
-
Latest Led 22mm Indicator Lamp 110vNegotiableMOQ: 10 Pieces
-
16mm Indicator Lamp 24v 220vNegotiableMOQ: 10 Pieces
Place of Origin
Zhejiang, China
Brand Name
KND
Model Number
E6-XD . E6-XDF. E6-XDJ
Type
LED
Package Type
Other
Max. Forward Voltage
Other
Max. Reverse Voltage
Other
Max. Forward Current
Other
Max. Reverse Current
Other
Specifications
1.push button switch with indicator2.many colors available
3.good quality
Description
Zhejiang Kenaida push button CO.,LTD is a professional push button and indicator manufacturer,Through years of painstaking operation and development , we had own more than 30 series of push button and accessories , and researched 1-2 series of new products.
These are our company's models in the picture .please remind us which type and color you want .whether you want neutral(no brand) or our brand on the goods? also remind us . if you don't remind , we will sent the goods at random .thank you .If you want one piece ,please contact us.
| Rate Value | ||||
| Rated Current lth(A) | 5A | |||
| Rated Voltage (V) | 24V | 125V(110V) | 250V(220V) | |
| Direct-Current | 1A | 0.2A | 0.1A | |
| Alternating Current | P.F=1 | 5A | 3A | |
| P.F=0.7 | 3A | 2A | ||
| LED | |||||||||||
| Type | Bidirection LED | Neon Bulb | |||||||||
| Rated Voltage | AC/DC 6V | AC/DC 12V | AC/DC 24V | AC110V | AC220V | ||||||
| AC/DC 110V | AC/DC220V | ||||||||||
| Color |
|
|
|||||||||
| LED Life | 30000hours | 20000hours | |||||||||
| |||||||||||
| Performance Characteristics | |||
| Operational temperation | -25°c - +55 °c(No frozen) | ||
| Make Airiness around the product | |||
| Operational humidity | 45- 85%RH (No frost) | ||
| Contact Resistance | ≤50MΩ | ||
| Insulation Resistance | ≥100MΩ | ||
|
between the contact and the lamp pin | 2000V,AC50HZ,1min | |
| between the homopolar terminal | 1000V,AC50HZ,1min | ||
| between different terminal | 2000V,AC50HZ,1min | ||
| Endure Dibratility | 50HZ,1.2mm | ||
| Endure Impact | ≥10g | ||
| Life | auto-return button | 1000000 | |
| auto-return button,selector button | 500000 | ||
| emergency stop button , key button | 100000 | ||
