Help CenterHigh Speed Lace Braiding Machine
Related Products
-
Lace Making MachineNegotiableMOQ: 1 Set -
16spindles Rope Braiding Machine With Four HeadsNegotiableMOQ: 1 Set
-
High Speed Rope/Belt Braiding MachineNegotiableMOQ: 1 Set
-
Cordage Braiding Machine,High Speed Braiding Machine,Braiding MachineNegotiableMOQ: 1 Set
-
JC High Speed Braiding MachineNegotiableMOQ: 1
JC Series of High Speed Rope/Belt Braiding Machine
Model No. |
JC 4/16 |
JC 2/24 |
JC 2/40 |
JC 1/48 |
Heads |
4 |
2 |
2 |
1 |
Numble of Spindle |
16 |
24 |
40 |
48 |
Uses |
it is applied to producing a variety of spandex and non-spandex ropes and belts like cordages,strings,drawstrings,galloons,shoelaces, decorative and tensile ropes and belts,etc |
|||
Max Diameter of Fabric |
different according to different spindles |
|||
Capacity |
according to the raw materials,density of fabric and the size of gears 60-120m/hour/head for non-spandex fabric 30-60m/hour/head for spandex fabric |
|||
Max. Rotate Speed (r/min) |
360 |
320 |
300 |
300 |
Motor Power(KW) |
0.75 |
0.75 |
1.1 |
0.75 |
Input Voltage(V) |
220V,380V |
220V,380V |
220V,380V |
220V,380V |
Machine Size(m)(L*W*H) |
1.25*1.2*1.45 |
1.4*1.1*1.45 |
1.7*1.2*1.5 |
1.35*1.25*1.52 |
Bobbin Size(mm)(D*H) |
48*140 |
48*140 |
48*140 |
48*140 |
Machine Weight |
600KG |
|||
Detailed Product Description
High speed braiding machine is an equipment with high exactitude,high efficiency,low wastage and low noises,which absorbs foreign various advanced technique and combines with the present technical level in our country. It is applied to producing a variety of rope ribbons,shoestrings,flex,decorative ribbons and tensile.
Adopt the advanced way of frequency conversion regulation and control,apt to control rotational speed,and in the braiding spindle qualify for the next round of competitions some office device hang industry of entering etc.Replace the punching type operation with porcelain eyes(alumina),operate simple and easily when changing the line.The applicable raw materials are also very wide.It is difficute to break when weaving,and not to fray the raw materials surface,after weaving,there is higher quality naturally,if there are products of warp-heart,can use material shelf automatically,nomatter what size is the warp-heart can becorrect deliveried dosage.When yun out of the warp-heart or break the line,the machine will stop turning round automatically.So under the unattended situation,that is also very comfortable for the machine running,in order to increase the output and lower costs.
The applicable raw materials are very wide,it is suitable for wool,chemical fiber,PP yarn,wire,etc.It is applied to producing a variety of columned belts,flat belts,curtain ribbons,silk ribbons,decorative ribbons and the other spandex and non-spandex ribbons.
