Home > Products > Wire Drawing Machines > Super Fine Wire Drawing Equipment
Super Fine Wire Drawing Equipment
- shanghai
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | JIACHENG | |
| Model Number | JCJX-24VD | Usage | Drawing |
Product Description
super fine wire drawing equipment is mainly used to make wires from 0.12-0.45 mm to 0.04 - 0.12 mm with the speed of 1800 m/min. with the following advantages:
1. double inverters control
2. low slip ratio, ensure high quality wires
3. low noisy, high efficiency
4. easy operation
JCJX-24VD extremely fine wire drawing machine | |
Inlet diameter | Ø 0.12-Ø 0.45 mm |
Outlet diameter | Ø 0.04-Ø 0.12 mm |
Max. speed | 1800 rpm |
Max. Number of Drawing dies | 24 pcs |
Slip ratio of m/c | 8% |
Fix speed capstan slip ratio | 7% |
Capstan | Ceramic plasma |
Max. Capstan diameter | Ø 100 mm |
Fix speed capstan diameter | Ø 120 mm |
Machine frame | Welded by steel plate and profile |
Main motor | 4 kw, AC- motor |
Take-up motor | 2.2 kw A.C motor |
Correction system | Automatically control |
Dynamic control | Double converters control |
Transmission method | By flat belts |
Pay-off method | Pay-off with hairbrush |
Traversing method | Polished rod traversing |
Tension control | Weight balance |
Lubrication system | Spraying |
Take-up bobbins | Ø 160 mm |
Capacity for take-up | 10 kg |
Braking system | Electromagnetic braking |
Machine dimension | 1740 L×1300 W×1450 H mm |
Machine weight | 1700 kg |
