Specifications
al-mg alloy wire manufacturing machine1,double inverter control
2, making wire from 1.17mm to 0.1 mm
3, with CE ISO
al-mg alloy wire manufacturing machine is used for drawing fine al-mg wire from 1.17 mm to 0.1-0.4 mm. (the machine on the picture is our OEM product)
Machine type | JCJX-32 |
Control system | Traditional analog type |
Inverter control | Dual Inverter control |
Drawing dies No./Max. | 32 |
Inlet diameter | φ1.17mm |
Outlet diameter | φ0.1∼φ0.4mm |
Drawing line speed | 1200m/min |
Slip ratio of m/c | 15% |
Fix speed capstan slip ratio | 10% |
Frame | Ironed cast |
Capstan | Tungsten plasma capstan |
Main motor | 7.5KW |
Spooler motor | 2.2KW |
Capstan dia.(Max.) | φ160mm |
Fix speed capstan dia. | 2000 rpm |
Spool bobbin size | φ300 or according to customers requirements |
Send-out method | without axis |
Traversing unit | Motor type |
Transmission type | By chain |
Spooler control | PID synchronous spooler |
Detecting device | Air balance by swing arm |
Tension control | Air pressure type |
Max. loading capacity | 200KG |
Lubrication type | spray type |
Brake | Disc brake |
Power source | 380V 50/60HZ |
Lubricant oil capacity | 100Liter/minute |
3. Advantage:
1). Double inverter can keep the outlet wire precisely tension and the slip ratio of wire will be reduced to the minimum.
2). Machine’s body and other key components and parts are produced by our own factory, quality is reliable
3).High tension durably flat belt gain convenient replacement and low noise in operating.
4).we only use elcctronic components of international well-known manufactures,such as:Japan NSK bearing,Switzerland SKF belt,France Schneider electric and Shenzhen Inovance inverter ,some machine can equip with SIMENCE PLC
5).we have gotten ISO 9001:2008,CE and TUV certificate.
5.After-sell service
Pre-sale training:In order to guarantee the customers are able fully to operate the machine, if the customer need, we can help customer training, includes:
(1) Correct operating mode
(2) Correct maintenance way
(3) Remove simple problem
Guarantees
Since the shipment date, 12 month for mechanical part, and 6 month for electrical part.
About our company:
Jiangsu Jiacheng Machinery Co,.Ltd,was founded in 1990,owing a technical team formed by many experts and engineers,our company is concentrated on making the best products in China.we are professional manufacturer in making all kinds of high speed wire drawing machine,rigid frame standing machine,annealing and tinning machine,bunching machine,extruder and so on. And our products have exported to India,Iran,Pakistan,Vietnam,Malaysia,Kenya,Syria,Brazil,Egypt and so on.
Attend the exhibition:
