Home > Manufacturing & Processing Machinery > Metallic Processing Machinery > Metal Drawing Machinery > Copper Wire Drawing Machine With Annealing
US$ 20,000 - 38,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Inlet Diameter:
1.0-1.6 mm
Outlet Diameter:
0.2-0.65 mm
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Copper Wire Drawing and Annealing MachineUS$ 8,900 - 9,900MOQ: 1 Set -
Fine Copper Wire Drawing Machine With AnnealingUS$ 8,900 - 9,900MOQ: 1 Set
-
Copper Wire Drawing and Annealing MachineUS$ 20,000 - 38,000MOQ: 1 Set
-
High Speed Fine Wire Drawing Machine With AnnealerUS$ 24,000 - 25,500MOQ: 1 Set
-
Double Fine Wire Drawing Machines With AnnealingUS$ 8,000 - 8,000MOQ: 1 Set
Condition
New
Inlet Diameter
1.0-1.6 mm
Outlet Diameter
0.2-0.65 mm
Place of Origin
Jiangsu, China
Brand Name
Jiacheng wire making machine
Model Number
JC-14DT
Voltage
380V 50/60HZ
Power(W)
26
Dimension(L*W*H)
3.0m 1.1m 1.6m
Weight
3500
Certification
CE,ISO9001:2008,BV
Warranty
12 month for mechanical part, and 6 month for electrical part
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
copper wire drawing machine with annealing1,inverter control
2,making wire from 1.0-1.6 mm to 0.25-0.65 mm
3,with CE ISO
copper wire drawing machine with annealing is used for drawing fine copper wire from 1.0-1.6 mm to 0.25-0.65 mm.
Technical parameter of this electrical wire making machine:
| Inverter control | Double inverter control |
| Max.inlet Dia.(mm) | Ø1.0-1.6 mm |
| Outlet Dia.(mm) | Ø0.25-Ø0.65 mm |
| Max.Line speed(m/min) | 1200 |
| Body structure | Ironed cast |
| Drawing captan | Tungsten plasma capstan |
| Slip ratio of m/c(%) | 15 |
| Main motor power(kw) | 18.5 |
| Take-up motor power(kw) | 5.5 |
| Fix speed capstan Dia.(mm) | Ø268 |
| Transmission type | By gear |
| Lubrication type | Full immersion |
| Max.annealing voltage(V) | DC60 |
| Max.annealing current(A) | DC600 |
| Take-up bobbin size(mm) | Φ300/Φ400 |
| Traversing type | By motor |
| Tension control | Air pressure type |
| Brake | Disc brake |
| Weight(KG) | 3500 |
Advantage:
1). Double inverter can keep the outlet wire precisely tension and the slip ratio of wire will be reduced to the minimum.
2). This electrical wire making machine ’s body and other key components and parts are produced by our own factory, quality is reliable
3).High tension durably flat belt gain convenient replacement and low noise in operating.
4).This electrical wire making machine use elcctronic components of international well-known manufactures,such as:Japan NSK bearing,Switzerland SKF belt,France Schneider electric and Shenzhen Inovance inverter.
5).we have gotten ISO 9001:2008,CE and TUV certificate
About us:
Jiangsu jiacheng machinery CO.LTD was founded in 1990,owing a technical team formed by many experts and engineers,our company is concentrated on making the best products in china and many other countries. we are professional manufacturer in making all kinds of high speed wire drawing machine,rigid frame standing machine,annealing and tinning machine,bunching machine,extruder and so on.
Sincerely welcome you visit our factory !
