Specifications
we provide ccs/ cu-ca/ cca coating/plating production line machine.Copper coating machine feature:
1. Double floor water tank, save space.
2. Six rollers, the whole rack made of stainless steel.
3. Main motor by frequency control.
4. Take-up part controlled by torque motor, stable tension.
Machine model |
JCJX-3000A |
JCJX-5000A |
JCJX-8000A |
Control system |
Button type |
||
Main power control |
Controlled by electric motor |
||
Take-up power control |
Controlled by torque motor |
||
Wire diameter |
1.01.4mm |
1.201.80mm |
1.22.2mm |
Main motor |
2.2KW |
3.3/ 4KW |
4KW/ 5.5KW |
Take-up motor |
YLJ112-12 |
YLJ112-12/ |
YLJ132-16 |
Spool reel size |
300mm/ 400mm or according to customers requirement |
||
Take-up type |
Shaftless take-up M/C |
||
Traversing type |
Plam shaft type |
||
Transmission type |
Tri-angle belt, chain |
||
Line speed |
10m/min 120m/min |
||
Rectifier |
3000A |
5000A |
8000A |
Dimension(mm) |
15000*1200*1400 |
18000*1600*1600 |
20000*1800*1600 |
Weight |
3500KG |
5000KG |
6000KG |
More detailed info pls let me know, we will reply as soon as possible.
contact with Mr. Adam Lu
International Trade Dept.
Jiangsu Jiacheng Machinery Co., Ltd
TEL: 0086-512-5835-5305 , 0086-13773236564
FAX: 0086-512-5835-3355
