Specifications
CO2 laser marking machine for optical lenses1.High speed Garvo head
2.Fine, permanent marking effect
3.Powerful software
CO2 laser marking machine for optical lenses
Laser Marking Machine (ZJ-2626A/B)
Product Features
- CO2 RF metal laser source. High speed Garvo head. High marking precision and high speed.
- Laser generator's height is adjustable. Easy to use. And it can fit various laser marking lens.
- Long working time, Fine, permanent artistic marking effect, with powerful function software.
- It can achieve on-the-fly marking for serial number marks.
- Perfect up and down exhaust system, keeping environment-friendly and safety of processing.
- Fixed working table (ZJ-2626 A) and cross slide working table (ZJ-2626 B) optional.
Application
Applying to most of non-metal materials such as leather, jean, denim, carpet, glass, plastic, acrylic, wood, epoxy resin, ABS, polycarbonate, unsaturated polyester, ceramic, etc.
Technical Parameter
Laser type |
CO2 RF metal laser tube |
Laser power |
30W |
Marking area |
260mm×260mm |
Cutting table |
Zinc-iron honeycomb working table |
No-load max speed |
0-360000mm/min |
Repeating location accuracy |
±0.1mm |
Motion system |
offline motion controlling system, 5 inches LCD offline display |
Cooling system |
Air cooling |
Power supply |
AC220V ± 5% / 50Hz |
Format support |
AI, BMP, PLT, DXF, DST, etc. |
Standard collocation |
A: 550W exhaust fan B: 550W exhaust fan, workpiece rotary device with cross sliding table |
Optional collocation |
CO2 RF metal laser tube (70W), Constant temperature water chiller |
