Specifications
Co2 laser optical lenses marking equipment1.High speed Garvo head
2.Fine, permanent marks
3.On-the-fly marking serial number
Co2 laser optical lenses marking equipment
Laser Marking Machine (ZJ-2626A/B)
Product Features
- CO2 RF metal laser source. High speed Garvo head. High marking precision and high speed.
- Laser generator's height is adjustable. Easy to use. And it can fit various laser marking lens.
- Long working time, Fine, permanent artistic marking effect, with powerful function software.
- It can achieve on-the-fly marking for serial number marks.
- Perfect up and down exhaust system, keeping environment-friendly and safety of processing.
- Fixed working table (ZJ-2626 A) and cross slide working table (ZJ-2626 B) optional.
Application
Applying to most of non-metal materials such as leather, jean, denim, carpet, glass, plastic, acrylic, wood, epoxy resin, ABS, polycarbonate, unsaturated polyester, ceramic, etc.
Technical Parameter
Laser type | CO2 RF metal laser tube |
Laser power | 30W |
Marking area | 260mm×260mm |
Cutting table | Zinc-iron honeycomb working table |
No-load max speed | 0-360000mm/min |
Repeating location accuracy | ±0.1mm |
Motion system | offline motion controlling system, 5 inches LCD offline display |
Cooling system | Air cooling |
Power supply | AC220V ± 5% / 50Hz |
Format support | AI, BMP, PLT, DXF, DST, etc. |
Standard collocation | A: 550W exhaust fan B: 550W exhaust fan, workpiece rotary device with cross sliding table |
Optional collocation | CO2 RF metal laser tube (70W), Constant temperature water chiller |
