4K*2k UHD HDMI switch 3by1

Introduction
This is a high performance three HDMI input and one HDMI output switcher .  The system supports all 3D TV formats in addition to all HDTV formats up to 4Kx2K. Furthermore, the remote control gives uses to complete control over the selection of sources and makes the device incredibly user friendly.

Package

UHD 3x1 HDMI Switcher---------------------------------1Pcs

5V/1A DC power adaptor-------------------------------1Pcs

Remote Control--------------------------------------------1Pcs

38KHz IR Receiver Cable---------------------------------1Pcs

User manual-----------------------------------------------1pcs

Feature

• Ø        Compliant with HDMI2.0, HDCP2.2 and DVI 1.0;
• Ø        Support video format up to 4k2k@30Hz with 24bit RGB/YcbCR 4:4:4/YCBCR 4:2:2,and up to 4k2k@60Hz with 12bit YCBCR 4:2:0;
• Ø        Support 3D frame sequential video format up to 1080p@60;
• Ø        Support high resolution VESA mode video format up to QSXGA@60Hz;
• Ø        Supports LPCM 7.1CH, Dolby TrueHD, and DTS-HD Master Audio;
• Ø        Supports smart auto switch function;
• Ø        Supports IR and Panel button control;

Specification

Video Bandwidth             300MHz/10.2 Gbps

Input Ports                         3 x HDMI (Female type)

Output Ports             1 x HDMI (Female type)

Output Resolution           480i ~1080p50/60, 4Kx2K@24/30,

4k2k@60Hz with 12bit YCBCR 4:2:0,VGA~UXGA

ESD Protection                  Human Body model:   ±8 kV (air-gap discharge)

                                                                                     ±4 kV (contact discharge)

Power Supply                   5 V/1A DC

Dimensions                    64 mm (W) × 155mm (D) × 17 mm (H)

Weight                                 180 g

Chassis Material               Metal

Silkscreen Color                Black

Operating Temperature    0 °C~40 °C/ 32 °F~104 °F

Storage Temperature          −20 °C ~ 60 °C/−4 °F ~140 °F

Relative Humidity               20~90 % RH (non-condensing)

Power Consumption            2W
