Product Details
Condition: | New | Type: | Fabric Dust Collector | Efficiency: | 99.99% |
Minimum Particle Size: | 5um | Place of Origin: | Jiangsu, China | Brand Name: | Alpha Filter |
Model Number: | M 45 | Dimension(L*W*H): | 2100X2100X4500 | Weight: | 4400Kg |
Certification: | CE | Warranty: | 1 Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Sand dust collector / bag dust collector / dust collector design / dust collector manufacturer / baghouse filter / Stone dust collector
Descriptions:
Baghouse Dust Collectors use needle felt bags for filtrations and reverse pulse jet air to clean bags. The dust laden gas enters through the bags. Dusts are filtered by dustcake and fabric. The clean air exits through the outside the bags. After a set time of filteration, the control board ignites the actions of pulse valves. The valves release the compressed air and blow up the bags through nozzles on the blow pipes. Thus the bags are refreshed and continue to filter dusts. This type of bag dust collectors can be used for any industrial dust collections, even sticky or high temperature dusts.
Our Baghouse Dust Collectors are modular design. Multi modules can be combined into a large unit. Thus the baghouse has unlimited bags. Each module can be shipped in standard container, which greatly reduce the freight cost.
Features:
- Each modular can be shipped in standard container, greatly reduce the shipping freight.
- Most components pre-installed in factory to minimize installation on site. No welding work is required on site, which allows quickest erection of system.
- Highest efficiency and durable needle felt bags ensures reliable and high efficiency filtration performance.
- A wide range of media fabrics available to meet the needs of any industrial process.
- Deflector plate in the inlet to knocks down larger particles into the hopper reducing bag abrasion. Down flow entry style using gravity to utmost reduce the dust load on bags
- Each modular is available in different height to accommodate different airflow. Inlet and outlet are special designed to achieve optimal airflow.
- Minimum maintenance. Tool-free maintenance for filter bags & cages. Easy access doors on top of dust collectors.
- Handrail on top and pulse control weather hood are as standard components
Typical Applications:
Woodworking, Paper, Furnace, Coal, Cement, Lime, Asphalt, Fly ash, Fiberglass, Plastic and Stone dust collections
Needle Felt Bag Properties:
Fiber Type | Working Temp. | Abrasion | EnergyAbsorbsion | Filtration Property | Moist Heat | Alkalines | Mineral Acids | Cost |
Polypropylene | 77 ℃ | Excellent | Good | Good | Excellent | Excellent | Excellent | $ |
Polyester | 135 ℃ | Excellent | Excellent | Excellent | Poor | Fair | Fair | $ |
Acrylic | 130 ℃ | Good | Good | Good | Excellent | Fair | Good | $$ |
Fiberglass | 260 ℃ | Fair | Fair | Fair | Excellent | Fair | Poor | $$$ |
Aramid | 204 ℃ | Excellent | Good | Excellent | Good | Good | Fair | $$$$ |
Ryton (Rrocon) | 190 ℃ | Good | Good | Good | Good | Excellent | Excellent | $$$$$ |
P84 | 260 ℃ | Fair | Good | Excellent | Good | Fair | Good | $$$$$$ |
Teflon | 260 ℃ | Good | Good | Fair | Excellent | Excellent | Excellent | $$$$$$$ |
Needle Felt Bag Finish and Purpose:
Finish Type | Finish Purpose | Available |
Singe | Improved dust cake release | Polyester, Polypropylene, Acrylic, Ryton, P84 felts |
Glaze/Eggshell | Provide short-term improvement of cake release | Polyester, Polypropylene felts |
Silicone | Initial dustcake development and limited water repellency | Polyester felts and woven |
Flame Retardant | Retards combustibity | Polyester, Polypropylene felts and woven |
Acrylic Coatings | Improved filtration efficiency and cake release | Polyester and Acrylic felts |
PTFE Penetrating Finishing | Improved water and oil repellency; Limited cake release | Aramid felts |
Download Brochure:
To learn more about our products and download the brochure, please visit our website:
Advanced Design:
Factory Facilities:
Co-operation Customers:
Specifications:
Model | Bag Size (mm) | Bags | Filter Area | Valves |
M20 | 130X2000 | 90 | 73.47 M2 | 9 |
M25 | 130X2500 | 90 | 91.84 M2 | 9 |
M30 | 130X3000 | 90 | 110.21 M2 | 9 |
M35 | 130X3500 | 90 | 128.58 M2 | 9 |
M40 | 130X4000 | 90 | 146.95 M2 | 9 |
M45 | 130X4500 | 90 | 165.32 M2 | 9 |
