American brand ANVER, is the world's leading vacuum handling equipment manufacturers, and the leader in vacuum product industry since 1968. It has been known for it's trustworth, high quality, engineering, and top selling record.
Anver external extension tube vacuum handling control system is used stainless steel material, only Anver extension tube vacuum handling system installed pressure gauge on the control handle, to display if the workpiece has been sucked up and ready to enhance safety.
Vacuum tube type crane is especially suitable for frequent and rapidly promote the cartons, bags, casks, board, rubber block artifacts, the load can reach 15-300 kg. Release and ascension process is done through vacuum system. And don't need the electric hoist, don't need cylinder, also do not need special mechanical structure, we can use endotracheal suction lift to completely absorb, ascend and release the workpiece. It is a completely man-machine syncretic equipment, can make your work more easier.
This equipment can easily adapt to the personalized needs.The same kind of host can be equipped with the combination of different suction cups, assembly completely modular, convenient operation and maintenance.Quick response device with a built-in one-way valve and a large area of suction cups (safety coefficient is not less than 2.5 times) to prevent the case of workpiece falls suddenly if the power lose.
Packaging details: wooden pallet for export
fumigation-free
Delivery Detail: 10-15days
Main Features:
1. suitable for the handling of paper box, bag, barrel, rubber pieces
2. With vacuum pressure gauge, maximum load of 300 kg
3. suitable for feeding line and stacking
4. moving speed is 1 m/SEC, and with suspension function
5. workpiece lifting/lowering /absorbs/release is controlled by the same stem completion without workpieces damage
6.The SS304 stainless steel control unit, to meet the food grade requirements
7. efficient, safe, fast, and energy saving
| Vacuum Lift Tube Assembly Set Number | Lift Cm(in) | Extended Height Cm(in) | Compressed Height Cm(in) | Non-Porous Loads lb(kg) | Semi-Porous Loads lb(kg) | Porous Loads lb(kg) |
| VT090-2.5-A | 167(66) | 280(110) | 112(44) | 50(23) | 35(16) | 30(14) |
| VT100-2.5-A | 167(66) | 275(108) | 108(42) | 95(43) | 70(32) | 50(23) |
| VT120-2.5-A | 167(66) | 277(109) | 110(43) | 140(64) | 105(48) | 70(32) |
| VT140-2.5-A | 167(66) | 277(109) | 110(43) | 185(84) | 140(64) | 95(43) |
| VT160-2.5-A | 167(66) | 282(111) | 115(45) | 225(102) | 170(77) | 115(52) |
| VT180-2.5-A | 167(66) | 287(113) | 120(47) | 285(129) | 215(98) | 145(66) |
| VT200-2.5-A | 167(66) | 287(113) | 120(47) | 355(161) | 265(120) | 175(80) |
| VT250-2.5-A | 147(68) | 287(113) | 140(55) | 470(214) | 350(160) | 235(107) |
| VT300-2.5-A | 167(66) | 292(115) | 124(49) | 510(230) | 390(175) | 275(125) |
| VT350-2.5-A | 167(66) | 292(115) | 124(49) | 550(250) | 430(195) | 315(140) |
| VT2200-2.5-A | 167(66) | 310(122) | 143(56) | 610(277) | 455(207) | 305(138) |
