ANVER corporation self-powered vacuum lifter also called unpowered lifter, whole complete set of vacuum equipment without power, external control and other complex attachments. American ANVER, is the world's leading vacuum handling equipment manufacturers, since the 1968 has been the sales first in north American, it has reliable quality. Works principle : closed cylinder with a free movement piston, rubber roll film in seal between the piston and cylinder, the seal does not depend on the contact between the metal and close cooperation, it has always been sealing role in the process of equipment operation.
Packaging details: wooden pallet for export
fumigation-free
Delivery Detail: 10-15days
Main Features:
1. without additional power supply
2. the maximum load can reach 5000 kg
3. variety of structure and suction cups are available for configuration
4. apply to the high temperature of 300 degrees
5. can design as your special request
6.The company passed the ISO9001, products have passed CE certification
| Type | Vacuum lifter Series | Typical Sheet Size(m) | Load(Kg) |
| Single Pad | M70S | 2.4*1.8 | 320 |
| M150S | 1.8*1.8 | 700 | |
| Two Pad | M50M2 | 2.1*1.2, 2.4*1.8 | 220 |
| M100M2 | 2.1*1.2, 2.4*1.8, 3.6*1.8 | 450 | |
| M200M2 | 0.9*1.8, 3.6*1.8 | 900 | |
| M300M2 | 2.4*1.8, 3.6*1.8 | 1300 | |
| M420M2 | 3.6*1.8 | 1900 | |
| Three Pads | M75M3 | 2.4*1.5, 0.9*1.5, 3.6*1.8 | 340 |
| M150M3 | 2.4*1.8, 0.9*1.8, 3.6*1.8, 4.8*1.8 | 680 | |
| M300M3 | 0.9*1.8, 3.6*1.8, 4.8*1.8 | 1300 | |
| Four Pads | M200M4 | 0.9*1.8, 3.6*1.8, 4.8*1.8, 6*1.8 | 900 |
| M400M4 | 3.6*1.8, 4.8*1.8, 7.2*1.8 | 1800 | |
| Four Pads with adjustable beam | M50M4 | 0.9*1.8, 3.6*1.8 | 220 |
| M83M4 | 0.9*1.8, 3.6*1.8 | 370 | |
| M100M4 | 0.9*1.8, 3.6*1.8 | 450 | |
| M200M4 | 0.9*1.8, 3.6*1.8 | 900 | |
| M400M4 | 3.6*1.8 | 1800 | |
| Six Pads with adjustable beam | M90M6 | 2.4*1.8, 0.9*1.8, 3.6*1.8 | 410 |
| M120M6 | 0.9*1.8, 3.6*1.8 | 540 | |
| M150M6 | 0.9*1.8, 3.6*1.8, 4.8*2.4 | 680 | |
| M300M6 | 3.6*1.8, 4.8*2.4 | 1300 | |
| Eight Pads with adjustable beam | M90M8 | 0.9*1.8, 3.6*1.8 | 410 |
| M90M8 | 0.9*6, 3.6*1.8, 4.8*2.4, 6*2.4 | 540 | |
| M90M8 | 0.9*1.8, 3.6*1.8 | 730 | |
| M90M8 | 0.9*1.8, 3.6*1.8, 4.8*2.4, 6*2.4, 7*2.4 | 900 | |
| M90M8 | 3.6*1.8, 4.8*2.4, 6*2.4, 7*2.4 | 1800 |
