China Manufacturer Automatic Mixing Machine Supplier For Powder Coating :
FHJ Auto Pre Mixer Series
A. Main characteristic:
1. Mobile hoppers to provide continuous loop production
2.High automatic: positioning, lock, overturning mixing and tank replacement
3. PLC control
4. Sufficient mixing, no solid powder
5. High efficiency
6. Easy to clean(for changing color)
7. Safe operation
8. Manual and auto two working way
B. Application:
This machine will improve production efficiency and decrease work intensity in mixing process.
C. Main characteristic:
1.Touch screen control
2. First time use the patent technology into the auto pre-mixer
3. Double direction mixing
4. Adjustable position during mixing
5. Double direction crushing
6. Collecting system while stopping
7. Easy to clean and change color
D. Main Technical Parameter:
Model |
Volume (L) |
Capacity (kg/tank) |
Mixing motor (kw) |
Rotary motor (kw) |
Crushing motor (kw) |
Lifting motor (kw)*2 |
Mixing time (min) |
Mixing speed (rpm) |
Overall dimension (mm) |
FHJ-300A |
300 |
100~200 |
9~11 |
0.55 |
- |
0.25 |
5~10 |
88~130 |
1755*1072*2315 |
FHJ-600G |
600 |
300~400 |
18.5~22 |
0.75 |
3.0 |
0.37 |
5~10 |
63~95 |
2550*1300*2900 |
FHJ-1000A |
1000 |
500~600 |
26~32 |
1.1 |
3.0 |
0.75 |
5~10 |
45~65 |
|
FHJ-1000G |
1000 |
500~600 |
26~32 |
1.5 |
3.0 |
0.75 |
5~10 |
45~65 |
|
E. Machine Pic.
1. Auto Premixer
2.Auto Premixer Container
Machine Part:
1. New Type Feeding Station:
Factory Pic:
Yuanli Manufacturing Company Welcome u visit us!!
