Help Center12v Car Power Inverter 500w 110v/120v/220v
Related Products
-
300w Car Power Inverter 110v/120v/220vUS$ 9.5 - 16.5MOQ: 100 Units -
12v Car Power Inverter 200w 110v/120v/220vUS$ 9 - 15MOQ: 100 Units
-
ac to dc Mini Solar Power Inverter 800w-1200w , Original FactoryUS$ 23 - 44.5MOQ: 100 Units
-
dc to ac 500w Camping Power InverterUS$ 16 - 23MOQ: 100 Units
-
200W 12V DC to AC Car Power Inverter With USBUS$ 8.9 - 17MOQ: 100 Units
Specifications
car power inverter 500w1.mini solar inverter price(cheap)
2.high quality for car power inverter
3.CE ROSH UL certificated
Specifications
1.Mini size
2.High efficiency
3.modified sine wave
4.12v/24v dc
12v/230v inverter 500w
1.Inverter Features:
Output voltage: 100-120V/220V-240V
Output frequency: 50Hz/60Hz
Output waveform: modified sine wave
Output socket type: suitable for any socket type LED indicator shows power on and fault conditionsInverter and charger function
switched by Auto-switchConnector: DC cable clips
2. Charger Feature
Three stages charging
For battery type: Lead-acid 12V DC Version/ Lead Acid 24V DC Version
Normal Output Voltage (DC): 12V/24V D
Charging voltage: 13.8V+-0.2 or 27.6V+-0.2
Charging Current: 5A/10A/20A
Protection: Protected against reverse polarity Overloadand short circuit protectionLow Battery Alarm,Low & High Battery Vol Shutdown,
Over temperature Shutdown,Overload protection,Short Circuit Protection,Input Reverse Protection
3.Specifications
12v 230v inverter 500w
Peak power:1000W
Dimension: 193*124*54mm
Net weight:830g
Certifications:ISO9001,UL,FCC,SAA,CE
4.Technical data:
| continuous power | 500W |
| peak power | 1KW |
| DC input voltage | 12V / 24V |
| AC Output voltage | 100 to 120V or 220V to 240V (selectable) |
| Output frequency | 60Hz or 50Hz |
| Output waveform | modified sine wave |
| Outlet | CP2, AP3, BP, GP and etc. |
| Connector | DC cable clips |
| Operating efficiency | >85 |
| Dimensions | 19.5x9.5x5.5cm |
| Net weight | 830g |
| No load current draw | <0.5A DC |
| Operating Temperature Range | -5°C~40°C |
| Storage Temperature Range: | -20°C~50°C |
| Operating relative humidity | 10%-90% |
| Storage relative humidity | 5%~95% |
| Connector | DC cable clips |
| Low voltage alarm | 10.5V / 21V |
| Low Voltage shutdown | 10.0V / 20V |
| High Voltage shutdown | 15V / 30V |
| Input reverse protection | Yes |
| Over load protection | Yes |
| Short circuit Protection | Yes |
| Over temperature shutdown | <65 0C |
