Specifications
various size of stainless steel tank:1.Made of SUS304;
2.Cylinder shape;
3.agitator;
4.CIP cleaning ball etc.
Specifications
Our factory supplies manufacturing various stainless steel tanks with or without jacket, agitation etc.
Our factory manufactures single-layer, dual-layer and three-layer stainless steel tanks with or without agitation to blend product, with a wide capacity range from 100L to 10,000L and even larger.
Single-layer tanks are widely applied in the beverage, food, dairy, pharmaceutical, chemical and process industries used as blender tank, buffer tank and storage tank, which cleanable to sanitary standards (e.g. FDA, USDA standards).
Configuration:
1) Manhole
2) CIP cleaner
3) Adjustable triangle bracket
4) Ladder
5) Thermometer
6) Liquid lever meter and controller
7) Eddy-proof board
8) Dismountable Inlet assembly
9) Sanitary breathing cover
Specification list
Model |
(L) Diameter |
External diameter |
Heightmm |
Insulationδ |
Jacketδ |
Diameter of inlet/outlet |
BYDG-500 | φ500 | 800 | 2140 | 50 | 1.5 | φ38 |
BYDG-1 | φ1000 | 1050 | 2380 | 50 | 1.5 | φ38 |
BYDG-1.5 | φ1500 | 1180 | 2550 | 50 | 1.5 | φ38 |
BYDG-2 | φ2000 | 1340 | 2760 | 50 | 1.5 | φ38 |
BYDG-2.5 | φ2500 | 1420 | 2940 | 50 | 1.5 | φ38 |
BYDG-3 | φ3000 | 1540 | 3050 | 50 | 1.5 | φ38 |
BYDG-4 | φ4000 | 1650 | 3200 | 50 | 1.5 | φ38 |
BYDG-5 | φ5000 | 1780 | 3250 | 50 | 1.5 | φ38 |
BYDG-6 | φ6000 | 1900 | 3350 | 50 | 1.5 | φ38 |
BYDG-8 | φ8000 | 2100 | 3800 | 60 | 1.5 | φ65 |
BYDG-10 | φ10000 | 2300 | 4050 | 60 | 1.5 | φ65 |
BYDG-12 | φ12000 | 2520 | 4450 | 60 | 1.5 | φ65 |
