Help CenterLarge Capacity Stainless Steel Milk Storage Silo
Related Products
Stainless steel milk storage silo
Use: applicable for large milk collection centre, or for milk outdoor storage at large milk production plant; also used at other food and pharmacy factory for storage of liquid product.
This equipment is equipped with cleaning system, agitator, sight and view devices, also have attachments of thermometer and level indication meter.
specifications:
Material: all material used is high quality sus304-2B stainless steel, inner shellδ=3mm and out shellδ=2mm and cooling jacket δ=1.5mm;
Structure: cylindrical shape, conical top cover of 15 degree, with skirt base; with PU(Polyurethane) as heat insulation; with cooling dimple pad at tank wall and base.
Volume range: 20,000L-150,000L
Standard attachments
a) one air tight side manway
b) one side mounted agitator960rpm;
c) One PT100 thermometer, temperature range 0~100;
d) Two cip cleaning ball;
e) one aseptic sample valve;
f) anti butterfly and dirt air vent;
g) product inlet/outlet
h) cooling medium inlet/outlet
i) level sensor;
j) ladder with circle protection and protection fence at tank top
