YUMO ISMM2080 100PPR 5VDCrotary encoder hand wheel MPG cnc Manual pulse generator
- 10000 Piece / Pieces per Month
- Shanghai
- T/T Credit Card PayPal
You May Like
-
YUMO 45mm 60mm cnc rotary encoder machine MPG Manual Pulse Encoder
-
YUMO ISM6045-002-100B-5E industrial tooling machinery Installation site size 50.8mm hand manual rotary encoder
-
YUMO ISM8060 industrial tooling machinery Installation size 80mm hand manual encoder
-
YUMO ISMM1468-001-100B-5L 100pulses industrial tooling machinery hand manual rotary encoder for CNC machine tool
-
YUMO ISM6045-002-100B-12L4 industrial tooling machinery Installation site size 50.8mm hand manual rotary encoder
-
ISMM1468 100PPR 5VDC rotary encoder hand wheel MPG cnc Manual pulse generator
Product Details
| Place of Origin | Zhejiang, China | Brand Name | YUMO | |
| Model Number | ISMM2080-001-100B-5L | Usage | Speed Sensor | |
| Output | Analog Sensor |
Product Description
YUMO ISMM2080-001-100B-5L MPG
Manual Encoder for CNC Machine Tool ( ISMM2080 ) MPG
Suitable for manual pulse input type such as NC or Milling machinery
High reliability, terminal connection type
Power supply: 5V DC, 12V DC
Customer's logo is available
Application:
Industrial tooling machinery
1. ELECTRICAL SPECIFICATIONS
A). Output wave: Square wave
B). Output signals: A, B, (Line driver output A, A, B, B phase)
C). Current consumption: d100mA
D). Response Frequency: 0~20KHz
E). Output phase difference: 90*
F). Supply voltage: 5V DC, 12V DC
G). Signal level: IVHe85%Vcc, VLd0.3V
H). Number of pulses: 100 (Other number of pulse available on request)
I). Output circuit: Open collector NPN, Push pull, Line driver, Voltage
2. MECHANICAL SPECIFICATIONS
A). Signal position: 2 kind
B). Speed without sealing: 500rmp
C). Starting torque without sealing: 2.0x 10-2~6.0x 10-2Nm (+25*C)
D). Shock resistance: 980m/s2, 6ms, 2 times each on XYZ
E). Vibration proof: 50m/s2, 10~200Hz, 2 hours each on XYZ
F). Working life: MTBFe10000h (+25*C, 2000rpm)
G). Weight: Appraisal 740g
3. ENVIRONMENTAL SPECIFICATIONS
A). Working humidity: 30~85% (No condensation)
B). Storage temperature: -30*C~85*C
C). Working temperature: -10*C~70*C
D). Protection class: IP54 MPG
