YUMO 10X10 Dia 50mm L 51 Cost-effective Single Disc Rotary Encoder aluminum alloy Couplings

Coupling Features:

Plate springs coupling;
Excellent response and high torque capacity;
Zero backlash;
Identical clockwise and anticlockwise rotational characteristics;
Stainless steel plate springs absorb angular misalignment and shaft end-play;

Coupling Capacity:

Transfer nominal torque Tn=2.8~80N. M
Allowable speed N=6000rpm
High resistance, constant velocity turning.
1° Limited angle deviation:
± 0.15mm Limited axle deviation: ± 0.15mm
Stainless steel with high causticity character and widely apply to coder and mini motor transmission.
Integration, minitype, low inertia.

YUMO 10X10 Dia 50mm L 51 Cost-effective Single Disc Rotary Encoder aluminum alloy Couplings YUMO 10X10 Dia 50mm L 51 Cost-effective Single Disc Rotary Encoder aluminum alloy Couplings YUMO 10X10 Dia 50mm L 51 Cost-effective Single Disc Rotary Encoder aluminum alloy Couplings YUMO 10X10 Dia 50mm L 51 Cost-effective Single Disc Rotary Encoder aluminum alloy Couplings YUMO 10X10 Dia 50mm L 51 Cost-effective Single Disc Rotary Encoder aluminum alloy Couplings
