four roller machine w12-16*2500/4-roller plate rolling machine
1. FEATURE OF 4 roller plate rolling machine
1.It is a kind of four-roller symmetrical machine with hydraulic pressure. It can shape steel board
into cylinder, U model etc.
2.The up roller is the main drive.Through the reducer output gear and gear meshing to provide torque for
coiled sheet.
3.The down roller make the vertical movement by the hydraulic cylinder.
4.Cone rolling is much easier.
5. Hydraulic drop end for ease of finished cylinder removal, and conical bending device.
6. Emergency system: safety string barrier around the machine and emergency push button.
2. Export standard configuration
No. |
Item |
Remark |
1 |
Main Motor |
Siemens(Germany) |
2 |
Electric parts |
Schneider(France) |
3 |
Hydraulic system |
Bosch – Rexroth (Germany) |
4 |
Seals |
VALQUA(Japan) |
5 |
PLC |
OMRON (Japan) |
6 |
Transducer |
OMRON (Japan) |
7 |
Touch screen |
Touch win (Canada) |
8 |
Mobile sensors |
KERUITE(Japan) |
3.Technical data
No. |
Specification |
Unit |
Parameter |
1 |
The model |
|
W12-16×2500 |
2 |
The plate yielding limit |
Mpa |
245 |
3 |
The max bend plate width |
mm |
2500 |
4 |
The max bend plate thickness |
mm |
16 |
4 |
The pre-bend plate thickness |
mm |
12 |
5 |
The diameter of up roller |
mm |
330 |
6 |
The diameter of bottom roller |
mm |
330 |
7 |
The diameter of side rollers |
mm |
260 |
8 |
The bend speed |
m/min |
5 |
9 |
The main motor power |
kW |
22 |
We can supply various specifications of Press Brake, Plate Shearing Machine & Rolling Machine, with or without CNC, according to customers' requirements.
We are also professional manufacturer of Punching Machine, Hydraulic Press, Iron Worker, Ventilation Equipment, Machine Tool Fittings, Bending Machine Dies, Punch Dies & Cutting tools.
All of our products have passed the ISO 9001 Quality System Certificate and CE Certificate.
If u want to know more information about our products, plz feel free to contact us!
Welcome to visit our company!
