Specifications
1BZ series hydraulic offset heavy duty disc harrow :1matched power:
1BZ hydraulic offset heavy duty disc harrow
1BZ series hydraulic pressure offset heavy disc harrow has the high working efficiency, strong capability
into the soil , and after plough loosen soil . this series can highly adapt to the sticky heavy soil ,
uncultivated field and those plots of many weeds . This harrow is made of square tubes welded together
which ensures simple structure and good rigidity .The harrow is also equipped with hydraulic lifting rubber
wheels for convenient transportation and small turning radius, thus the production efficiency and lifetime
of the harrow is dramatically improved .
Specifications
item |
unit |
1BZ-2.0 |
1BZ-2.2 |
1BZ-2.5 |
1BZ-3.0 |
1BZ-3.4 |
working width |
mm |
2000 |
2200 |
2500 |
3000 |
3400 |
Working depth |
mm |
200 |
||||
No. of disc |
pc |
18 |
20 |
24 |
28 |
32 |
Dia. Of disc |
mm |
660 |
||||
weight |
kg |
1150 |
1250 |
1350 |
1500 |
1650 |
linkage |
|
Trailed |
||||
matched power |
hp |
75-80 |
80-100 |
90-100 |
100-120 |
|
