Specifications
WS2812B RGB Digital LED Strip light1. Working Voltage: DC5V
2. LED Qty: 60leds/M
3. LED Type: SMD5050
4. IP20/65/67
5v WS2812B RGB Digital LED Strip light
ws2812b ic led strip light features:
1. 60leds/meter
2. Light source: 5050SMD;
3. Voltage: DC5V
4. IC Type: ws2812b (Built-in)
Parameter
LED Color |
RGB |
LED type |
SMD5050 |
LED Qty |
60pcs per meter(18w/m) |
IC Qty |
60pcs ws2812b |
Grey |
256 |
FPC Color/width |
white/10mm |
Working Voltage |
DC 5V |
Power Consumption |
18W per meter |
Pixel Qty |
60pcs |
Beam angle |
120 degree |
Waterproof Grade |
IP65/IP67 or no waterproof |
Lighting Decay |
less than 3% after 3000 hours |
led pixel |
60 |
Life Span |
50.000 hours |
Warranty |
2 year |
Features and Benefits:
- Control IC included, supporting numerous color-change effects;
- "Plug-in" controller with remote control;
- Flexible PCB, 5V low voltage input;
- Every 2 Leds linear separable, custom-length available;
- Eco-green light, no UV, IR;
- Extremely long lifespan & lower power consumption;
Connection:
1) Signal wire: DC+, DIN, GND
2) DC+ and GND connect to power supplier; DIN and GND connect to controller
3) Relative Controller: SPI controller support ws2811; when use DMX decorder, can connect to DMX system
4) Support online control
Installation Notice:
1) Make sure the connection is correct according to the diagram
2) Pay attention to the parameters limit of voltage. DO NOT run over the peak value
3) Keep the surface of installation clean and smooth avoid breaking off
4) Avoiding the crook area just the position of LED and other components, in order to protect the product and extend the life span of the product
Application:
1.Personal DIY home decoration.
2.Route instructions and exterior decorative outline
3.Backlit billboards,advertising signs,channel signal signs
4.Festive decorations,activities,venue set,exhibition decoration,hall decoration.
5.Hotels and other entertainment decorated KTV
