Specifications
LED Panel lighting1. Dimensions:30x30cm;
2. Power: 12w
3. LED Qty: SMD5050 72pcs
4. CE RoHS
RGB Color Changing LED Panel Lighting
Introduction:
300x300mm LED Panel Lamp with light emitting from 2 edges and controlled by DMX512. It is made up of high efficiency light guide plate + high effect diffusion plage + high quality AL6063 Aluminum + high bright low current SMD5050 LEDs.
It has 16kinds of single color ( Red, green, blue) and 1 kind of gradual changing color.
Three kinds of frame color: Silver & white & black are offered for customers to choose from. Not only it can be suspended, but also it can be recessed & surface mounted. Single 300x300 RGB LED Panel or Multy RGB 300x300 led light panel can be dimmed by DMX512 controller.
Technical Parameters of 12w 300x300x12mm DMX LED RGB Panel :
| 1 | Dimension(mm) | 300x300x12mm |
| 2 | Wattage (W) | 12w |
| 3 | Luminous Flux (LM) | 500-550LM |
| 4 | Input Voltage (V) | AC100-240V |
| 5 | Output Voltage (V) | DC24V |
| 6 | Light way | Emitting light from 2 edges |
| 7 | Material | PMMA+Aluminum |
| 8 | Light Color | RGB Full Colors) (16 kinds of single colors+1 kind of gradual changing color |
| 9 | Dimmable way | by RGB IR Dimmer & DMX 512 |
| 10 | Frame Color | White/Silver /Black |
| 11 | Installation | Hanging & Surface Mounted & Recessed |
| 12 | Certificates | CE/ROHS/EMC |
| 13 | Warrange time | 2 years |
| 14 | Gross weight | 2kg/pcs |
| 15 | Package | 1pcs/inner box , 5pcs/carton |
| 16 | Carton Size | 38x32x46cm |
LED Panel Light Features:
1. The light design is in accord with the principle of led plane lighting, ideal for illumination.
2. Instant start, no flickering.
3. Apply the high lumen SMD5050 as light source to insure high luminous flux and conformity light output.
4. Elegant design by smooth aluminum frame and PC cover.
5. Supending by links or surface mounted is available
Warranty:
Products returned within the warranty period must bear Absen product number & date code. Products of unknown sources or without valid marking will not be accepted.
Replacement items will be sent together with customer's next order shipment
Application:
- KTV
- Bars
- Club
- Dancing Hall
- Entertainments
