lab colorimeter NR200
Application:
The colorimeter is widely used in plastic, metal, electronic, paint, ink, textile, garment, printing and dyeing, food, medical, cosmetic, automotive, toy...industries. It with the below advantages:
Leading Humanity Design and Convenient Operation:
One-touch access to measurement interface; Structure design in line with ergonomics
Stable Measurement Performance :
The repeatability E is 0.08.; Portable structure design is more conductive to keeping the instrument stable when using.
Convenient and Fast L℃ating:
Illumination l℃ating is a fast, simple and convenient l℃ating
PC S℉tware—Realize More Function Expansion:
Perform color difference analysis,color difference cumulative analysis,chromaticity index, color sample database management,
simulating object color, etc.
Advanced Power Management Design:
using high capacity Li-ion battery in colorimeter. It can measure more than 3000 times on one charge to ensure the stability ℉
long time measurement.
Technical Specifications:
Illuminating/Viewing Geometry |
8/d |
Measuring Aperture |
Φ8mm |
Detector |
Silicon photoelectric diode |
Color Space |
CIEL*a*b*C*h* CIEL*a*b* |
Color Difference Formula |
E*ab L*a*b E*C*h |
Light Source / Light Source Device |
D65 / LED blue light excitation |
Errors Between Each Equipment |
≤0.50 E*ab |
Storage |
100pcs standards 20000pcs samples |
Repeatability |
Standard deviation within ΔE*ab 0.08, Average ℉ 30 measurements ℉ standard white plate |
Dimension |
205*70*100 mm & 500g |
Power source |
Rechargeable lithium-ion battery 3.7V@3200mAh |
Lamp Life |
3 years, more than 1 million measurements |
Charging Time |
8 hours--100% electricity |
Measurement Times Before Recharging |
3000 times in 8 hours |
Operating Temperature/Humidity Range |
-10~40℃, relative humidity 0~85% with no condensation |
Data Interface / Optional Accessory |
USB /Miniature thermal printer, Powder Test Box |
