ISO Ceritified ALNICO MAGNETS FOR GUITAR PICKUP
- 1000000 Unit / Units per Month
- SHANGHAI
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Shanghai, China | Brand Name | Strong-Magnets | |
| Model Number | LN | Type | Permanent | |
| Composite | AlNiCo Magnet | Shape | Other, Numerous Shapes | |
| Application | Industrial Magnet |
Product Description
Specifications
ALNICO MAGNETS FOR GUITAR PICKUPSuper Strong and Permanent
Manufactured in compliance with ISO standards
ALNICO MAGNETS FOR GUITAR PICKUP
Alnico is widely used as guitar pickups. We supply alnico 3, alnico 5, alnico 8 and so on.
What is Alnico?
- Alnico is an alloy containing Aluminium (Al), Nickel (Ni), Cobalt (Co) hence named Alnico.
- Alnico alloys make strong permanent magnets, and can be magnetized to produce strong magnetic fields.
USES
Cast Alnico magnets are widely used in all kinds of sensors and meters, electronic instruments, medical instruments, vehicle parts,guitar pickups, aviation etc.
ALNICO MAGNETS FOR GUITAR PICKUP
|
Compact crystal, high intensity, good chemistry stability, stong anti-corrosion, even elements, exceelent and magnetic performance, excellent temperature stability, highest usage temperature reach 500 degree.
|
Grade: alnico2 /alnico5/alnico8
|
Grade |
Br |
Hcb | t(BH)max |
α(Br) |
α(Hcj) |
mT Gs | kA/m Oe | kJ/m3 MGOe | %K | %K | |
LN10 | 600/6000 | 40/500 | 10.00/1.20 | -0.02 | 0.03 |
LNG12 | 700/7000 | 44/550 | 12.00/1.50 | -0.02 | 0.03 |
LNG13 | 680/6800 | 48/600 | 13.00/1.63 | -0.02 | 0.03 |
LNG18 | 900/9000 | 48/600 | 18.00/2.25 | -0.02 | 0.03 |
LNG37 | 1200/12000 | 48/600 | 37.00/4.63 | -0.02 | 0.03 |
LNG40 | 1250/12500 | 48/600 | 40.00/5.00 | -0.02 | 0.03 |
LNG44 | 1250/12500 | 52/650 | 44.00/5.50 | -0.02 | 0.03 |
LNG52 | 1300/13000 | 56/700 | 52.00/6.50 | -0.02 | 0.03 |
LNG56 | 1300/13000 | 58/720 | 56.00/7.00 | -0.02 | 0.03 |
LNG60 | 1330/13300 | 60/750 | 60.00/7.50 | -0.02 | 0.03 |
LNGT18 | 580/5800 | 90/1130 | 18.00/2.25 | -0.02 | 0.03 |
LNGT30 | 1100/11000 | 56/700 | 30.00/3.75 | -0.02 | 0.03 |
LNGT32 | 800/8000 | 100/1250 | 32.00/4.00 | -0.02 | 0.03 |
LNGT38 | 800/8000 | 110/1380 | 38.00/4.75 | -0.02 | 0.03 |
LNGT44 | 850/8500 | 120/1500 | 44.00/5.50 | -0.02 | 0.03 |
LNGT48 | 900/9000 | 120/1500 | 48.00/6.00 | -0.02 | 0.03 |
LNGT60 | 950/9500 | 110/1380 | 60.00/7.50 | -0.02 | 0.03 |
LNGT72 | 1050/10500 | 112/1400 | 72.00/9.00 | -0.02 | 0.03 |
LNGT88 | 1100/11000 | 115/1450 | 88.00/11.00 | -0.02 | 0.03 |
LNGT36J | 700/7000 | 140/1750 | 36.00/4.50 | -0.02 | 0.03 |
LNGT52J | 900/9000 | 140/1750 | 52.00/6.50 | -0.02 | 0.03 |
Grade |
Br |
Hcj |
(BH)max |
Tc |
Tw |
aBr |
mT Gs | kA/m Oe | kJ/m3 MGOe | °C | °C | %/°C | |
FLN8 | 500/5000 | 40/500 | 9/1.13 | 760 | 450 | -0.022 |
FLNG12 | 700/7000 | 48/600 | 12.4/1.55 | 810 | 450 | -0.014 |
FLNGT18 | 600/6000 | 90/1130 | 18/2.20 | 860 | 450 | -0.02 |
FLNG34 | 1200/12000 | 48/600 | 34/4.25 | 890 | 450 | -0.016 |
FLNG37 | 1250/12500 | 48/600 | 37/4.62 | 890 | 450 | -0.016 |
FLNGT28 | 1050/10500 | 60/600 | 28/3.50 | 850 | 450 | -0.02 |
FLNGT38 | 800/8000 | 120/1500 | 38/4.75 | 850 | 450 | -0.02 |
FLNGT42 | 880/8800 | 120/1500 | 42/5.25 | 820 | 450 | -0.02 |
FLNGT33J | 700/7000 | 140/1750 | 33/4.13 | 850 | 450 | -0.025 |
QUALITY ASSURANCE
FOR QUOTATION, PLEASE WRITE TO US WITH THE FOLLOWING INFORMATION:
- PRODUCT NAME
- GRADE
- SIZE
- SHAPE
- COATING
- ORDER QUANTITY
