Auto Air Conditioning Trainer

Production description

The trainer chooses the auto air conditioning system as the base and is driven by motor. It can really show the structure and working principle of the auto air conditioning system. It is suitable for the theoretical teaching and practical operation of the auto air conditioning in the secondary vocational and higher vocational institutions. It can meet the teaching needs of the structure of auto air conditioning system.

Structure and composition

380V/220V motor, protection controller, compressor, dry bottle, HVAC, condenser assembly, cooling fan, A / C switch, blower switch, stack pluggable cable, supporting disassembly tools, pressure gauge, vacuum gauge, environmental connectors, bottle opener, ring, thermometer brake discs, power, color panel painted with high quality schematic, removable stand.

Features

1. It is base on the real car air conditioning system. It can fully display the structure and composition of the auto air conditioning system.

2. Students themselves install the air-conditioning piping and their abilities are enhanced, and connect the air conditioning lines (using cable to connect the entire air conditioning system line)

3.Students can do the following things like connecting the pipe installation, vacuum, detecting the leaking, linking lines, filling refrigerant, supporting the air conditioning pipe, cable, disassembly tools, testing, filling the refrigerant supporting tools and diagnosis.

4. Master the structure of fuse, relay, A / C switch, blower switch, blower resistor.

5. It can enhance students’ ability, judgment as well as their enthusiasm.

6. Fill and recycle the refrigerant.

Technical parameter:

1. Nylon casters: Diameter of 75mm, width 35mm, with locking casters;

2. Quality steel; 40x80x3.0 steel

3. Power supply: AC 220V, 50Hz; DC12V

4. Refrigrent: R134a

5. Safety fence: 3.0 stainless steel  , 6CM punching board

6. Stainless steel rails with square and round shape

7. Bracket material: 50x50x3mm

8. Detection terminals: 6mm stainless steel terminal, 6mmLED indicators

9. Dimensions: about 1000x1600x1800mm

10. Maintenance intervals: 90 days
