Home > Products > spiral wrap > Professional manufacturer spiral wrap for wire and cable management
Professional manufacturer spiral wrap for wire and cable management
- 100000 Meter / Meters per Month
- Tianjin or according to customer
- T/T L/C D/P D/A Credit Card PayPal
- NQ core drill bits,diamond bits
- Cost effective Concrete thin wall core bits,diamond tipped core bits
- Long life CSC-120 crawler mucking loader ,tunnelling machine
- Thin Wall Wet Diamond Core Drill Bits
- R32 51mm EXX TC tipped Cross bits,drilling bits,taper bits
- H22 tapered dill steels for small hole drilling
Product Details
Place of Origin: | Hebei, China | Brand Name: | HAO | Model Number: | Spiral Wrap |
Type: | Spiral Wrapping | Material: | Other, PE, PP, PE, PA or other rubber |
Product Description
Professional manufacturer spiral wrap for wire and cable management can be used in excavator,paver,roller,loader,pumping machinery and also some other molding equipment.
Its function is to enhance the wear resistance an ultraviolet resistance of hydraulice hose,in various harsh environment protection of hydrarlic hose.
Product name | Professional manufacturer spiral wrap for wire and cable management |
Material | PP, PE, PA |
Producing way | Extrusion |
Hardness | 85A-90A |
Temperature resistance | -40°C-120°C |
Tensile Strength | 25MPa at normal temperature, 30MPa at -40 °C |
Impact Strength | 35KJ/sqm at normal temperature, 5KJ/sqm at -40 °C |
Inner diameter | 8mm-200mm |
Outer diameter | 10mm-300mm |
Shape | convex surface and flat surface |
Color | any color |
Application | Mainly installed in the hydraulic hose, wire and cable products external. |
Craft: | Best Vulcanization and Microwave courting |
Packaging |
(1) 2 meters/root discharge a layer and two layers are separated by the thin cardboard in a carton (200*40*20mm). (2) Length per customer's requirement in one roll. (3) According to customer requirements. |
Professional manufacturer spiral wrap for wire and cable management Specification:
Part Number | Size (ID) | Wall Thickness(mm) | Width(mm) | Bundle Diameter Range(mm) | |
mm | inch | ||||
DY-08 | 8 | 5/16" | 1.1 | 7.0 | 8-12 |
DY-10 | 10 | 3/8" | 1.1 | 10.0 | 9-11 |
DY-12 | 12 | 1/2" | 1.1 | 12.0 | 11-14 |
DY-14 | 14 | 11/20" | 1.5 | 13.0 | 13-16 |
DY-16 | 16 | 5/8" | 1.5 | 15.5 | 15-18 |
DY-18 | 18 | 3/4" | 1.8 | 16.0 | 17-20 |
DY-20 | 20 | 4/5" | 1.8 | 16.0 | 19-22 |
DY-22 | 22 | 43/50" | 2.0 | 19.5 | 20-26 |
DY-25 | 25 | 1" | 2.0 | 22.5 | 25-29 |
DY-28 | 28 | 1-1/10" | 2.0 | 23.0 | 28-32 |
DY-30 | 30 | 1-9/50" | 2.0 | 23.0 | 30-35 |
DY-32 | 32 | 1-1/4" | 2.2 | 23.5 | 32-38 |
DY-35 | 35 | 1-19/50" | 2.2 | 24.0 | 35-40 |
DY-38 | 38 | 1-1/2" | 2.5 | 28.0 | 38-40 |
DY-40 | 40 | 1-29/50" | 2.5 | 28.0 | 39-42 |
DY-42 | 42 | 1-13/20" | 2.5 | 28.0 | 42-49 |
DY-45 | 45 | 1-39/50" | 3.0 | 28.0 | 45-52 |
DY-50 | 50 | 2" | 3.0 | 28.0 | 50-60 |
DY-60 | 60 | 2-1/2" | 3.0 | 28.0 | 60-74 |
DY-74 | 74 | 2-9/10" | 4.0 | 46.5 | 70-85 |
DY-80 | 80 | 3-3/20" | 4.5 | 48.5 | 80-85 |
DY-88 | 88 | 3-1/2" | 4.5 | 50.0 | 85-98 |
DY-100 | 100 | 4" | 4.5 | 57.0 | 95-135 |
DY-130 | 130 | 5" | 4.5 | 50.0 | 130-155 |
DY-150 | 150 | 6" | 5.0 | 50.0 | 150-175 |
The pictures are just samples of protective spiral safe tube . We can manufacture as customer's drawings or requirements.
We are factory.
For the same product, we have lower price.
For the same service, we are more reliable.
We can produce the protective spiral safe tube as your requirements.
If you have any questions, please contact with us, and we will reply ASAP.
