color foot Style Headphone&Earphone rubber Wrap Cable tidy

FOB Price

USD $0.8 - $1 / Meter

1000 Meters(Min.Order)

Supply Ability 100000 Meter / Meters per Month
Port Tianjin or according to customer
Payment Terms:T/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:	Hebei, China	Brand Name:	HAO	Model Number:	Spiral Wrap
Type:	Spiral Wrapping	Material:	Other, PE, PP, PE, PA or other rubber

Product Description

color foot Style Headphone&Earphone rubber Wrap Cable tidy can be used in excavator,paver,roller,loader,pumping machinery and also some other molding equipment.

Its function is to enhance the wear resistance an ultraviolet resistance of hydraulice hose,in various harsh environment protection of hydrarlic hose.

Product name	color foot Style Headphone&Earphone rubber Wrap Cable tidy
Material	PP, PE, PA
Producing way	Extrusion
Hardness	85A-90A
Temperature resistance	-40°C-120°C
Tensile Strength	25MPa at normal temperature, 30MPa at -40 °C
Impact Strength	35KJ/sqm at normal temperature, 5KJ/sqm at -40 °C
Inner diameter	8mm-200mm
Outer diameter	10mm-300mm
Shape	convex surface and flat surface
Color	any color
Application	Mainly installed in the hydraulic hose, wire and cable products external.
Craft:	Best Vulcanization and Microwave courting
Packaging	(1) 2 meters/root discharge a layer and two layers are separated by the thin cardboard in a carton (2004020mm). (2) Length per customer's requirement in one roll. (3) According to customer requirements.

color foot Style Headphone&Earphone rubber Wrap Cable tidy Specification:

Part Number	Size (ID)		Wall Thickness(mm)	Width(mm)	Bundle Diameter Range(mm)
Part Number	mm	inch	Wall Thickness(mm)	Width(mm)	Bundle Diameter Range(mm)
DY-08	8	5/16"	1.1	7.0	8-12
DY-10	10	3/8"	1.1	10.0	9-11
DY-12	12	1/2"	1.1	12.0	11-14
DY-14	14	11/20"	1.5	13.0	13-16
DY-16	16	5/8"	1.5	15.5	15-18
DY-18	18	3/4"	1.8	16.0	17-20
DY-20	20	4/5"	1.8	16.0	19-22
DY-22	22	43/50"	2.0	19.5	20-26
DY-25	25	1"	2.0	22.5	25-29
DY-28	28	1-1/10"	2.0	23.0	28-32
DY-30	30	1-9/50"	2.0	23.0	30-35
DY-32	32	1-1/4"	2.2	23.5	32-38
DY-35	35	1-19/50"	2.2	24.0	35-40
DY-38	38	1-1/2"	2.5	28.0	38-40
DY-40	40	1-29/50"	2.5	28.0	39-42
DY-42	42	1-13/20"	2.5	28.0	42-49
DY-45	45	1-39/50"	3.0	28.0	45-52
DY-50	50	2"	3.0	28.0	50-60
DY-60	60	2-1/2"	3.0	28.0	60-74
DY-74	74	2-9/10"	4.0	46.5	70-85
DY-80	80	3-3/20"	4.5	48.5	80-85
DY-88	88	3-1/2"	4.5	50.0	85-98
DY-100	100	4"	4.5	57.0	95-135
DY-130	130	5"	4.5	50.0	130-155
DY-150	150	6"	5.0	50.0	150-175

The pictures are just samples of protective spiral safe tube . We can manufacture as customer's drawings or requirements.

We are factory.

For the same product, we have lower price.

For the same service, we are more reliable.

We can produce the protective spiral safe tube as your requirements.

If you have any questions, please contact with us, and we will reply ASAP.
