2CL70 Chinese Factory High Voltage Fast Recovery Rectifier Diodes

2CL70 Chinese Factory High Voltage Fast Recovery Rectifier Diodes thumbnail-1
2CL70 Chinese Factory High Voltage Fast Recovery Rectifier Diodes photo-1
US$ 0.01 - 1 MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Liaoning, China
Brand Name:
Leadsun
Model Number:
2CL70A
Contact Supplier Request Quote Chat Now
Anshan Leadsun Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Liaoning, China
Brand Name Leadsun
Model Number 2CL70A
Type Rectifier Diode
Package Type Surface Mount
Max. Forward Voltage 51V
Max. Reverse Voltage 6KV
Max. Forward Current 5mA
Max. Reverse Current 2.0uA
Product Description

2CL70 high voltage diodes adopt the designing of high reliable multiple mesa structure and silicon tube, molded in small volume and compact packaging surface by epoxy resin.

2CL70 high voltage diodes adopt the designing of high reliable multiple mesa structure and silicon tube,
molded in small volume and compact packing surface by epoxy resin.
Features:
Fast recovery
Low forward on pressure, low leakage current
Protection of avalanche breakdown
Antiimpacting of discharging of CRT high voltage surge current
Axia lead diode, could weld on tube pin
Epoxy resin molded and can resist corrosion on its surface
Application:
Television and FBT display
Cathode ion generator, laser power supply
Neon lamp power supply, voltage multiplier assembly
DC high voltage generator assembly

■MAX.RATED VALUE

Rated Value
Sign
Condition

Unit
Peak Reverse Repetitive Voltage
VRRM
6
KV
Average Forward Rectifier Current
Io
5.0
mA
Max. Irrepetive Surge Current
IFSM
Ta=25℃，rated load，half cycle，single phase，50Hz
0.5
A
Junction Temperature
Tj
half cycle sinewave peak voltage
120
℃
Ambient Humidity
Tc
100
℃
Store Humidity
Tstg
-40~120
℃

■Electric Characteristic

Rated Value
Sign
Condition

Unit
Max. Forward Peak Voltage
V
IF=10mA
6
V
Max. Reverse Recovery Time
trr
IF=2mA   IR=4mA
0.1
μS
Max. Reverse Leakage Current
IR1
VR=VRRM, 25℃
2.0
μA
Max. Reverse Leakage Current
IR2
VR=VRRM, 100℃
5.0
μA
Max. Junction Capacitor
Cj
2
pF
Related Products
Packing & Shipping

Packing: 200 pcs in one bag, 25 bags in one carton
