Home > Products > cutting tool > hand and machine operated tap
hand and machine operated tap
US$ 0.35 - 17
/ Piece
10 Pieces(Min. Order)
- qingdao xingang
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | zhongyi | |
| Model Number | M2,M3,M4,M5 etc |
Product Description
Product Description
Hand and machine operated tap
Coarse Thread
| GB3464.1 | GB3464.2 | GB3464.3 | |||||||
| size | overall length | thread length | outside diam | overall length | thread length | outside diam | overall length | thread length | outside diam |
| M2 | 41.0 | 8.0 | 2.5 | - | - | - | 36.0 | 8.0 | 2.5 |
| M2.5 | 44.5 | 9.5 | 2.8 | - | - | - | 36.0 | 9.5 | 2.8 |
| M3 | 48.0 | 11.0 | 3.15 | 66.0 | 11.0 | 2.2 | 40.0 | 11.0 | 3.15 |
| M4 | 53.0 | 13.0 | 4.0 | 73.0 | 13.0 | 3.2 | 45.0 | 13.0 | 4.0 |
| M5 | 58.0 | 16.0 | 5.0 | 79.0 | 16.0 | 4.0 | 50.0 | 16.0 | 5.0 |
| M6 | 66.0 | 19.0 | 6.3 | 89.0 | 19.0 | 4.5 | 55.0 | 19.0 | 6.3 |
| M7 | 66.0 | 19.0 | 5.6 | 89.0 | 22.0 | 5.6 | 55.0 | 19.0 | 5.6 |
| M8 | 72.0 | 22.0 | 6.3 | 97.0 | 24.0 | 6.3 | 65.0 | 22.0 | 6.3 |
| M10 | 80.0 | 24.0 | 8.0 | 108.0 | 29.0 | 8.0 | 70.0 | 24.0 | 8.0 |
| M12 | 89.0 | 29.0 | 9.0 | 119.0 | 30.0 | 9.0 | 80.0 | 29.0 | 9.0 |
| M14 | 95.0 | 30.0 | 11.2 | 127.0 | 32.0 | 11.2 | 90.0 | 30.0 | 11.2 |
| M16 | 102.0 | 32.0 | 12.5 | 137.0 | 37.0 | 12.5 | 90.0 | 32.0 | 12.5 |
| M18 | 112.0 | 37.0 | 14.0 | 149.0 | 37.0 | 14.0 | 100.0 | 37.0 | 14.0 |
| M20 | 112.0 | 37.0 | 14.0 | 149.0 | 37.0 | 14.0 | 100.0 | 37.0 | 14.0 |
| M22 | 118.0 | 38.0 | 16.0 | 158.0 | 38.0 | 16.0 | 110.0 | 38.0 | 16.0 |
| M24 | 130.0 | 45.0 | 18.0 | 172.0 | 45.0 | 18.0 | 120.0 | 45.0 | 18.0 |
| M27 | 135.0 | 45.0 | 20.0 | - | - | - | 120.0 | 45.0 | 20.0 |
| M28 | 127.0 | 37.0 | 20.0 | - | - | - | 105.0 | 37.0 | 20.0 |
| M30 | 138.0 | 48.0 | 20.0 | - | - | - | 130.0 | 48.0 | 20.0 |
| M33 | 151.0 | 51.0 | 22.4 | - | - | - | 130.0 | 51.0 | 22.4 |
| M36 | 162.0 | 57.0 | 25.0 | - | - | - | 145.0 | 57.0 | 25.0 |
Fine Thread
| GB3464.1 | GB3464.2 | GB3464.3 | |||||||
| Size | Overall length | Thread Length | Outside diam | Overall Length | Thread length | Outside diam | Overall length | Thread length | Outside diam |
| M2x0.25 | 41 | 8.0 | 2.50 | - | - | - | 36 | 8.0 | - |
| M3x0.35 | 48 | 11.0 | 3.15 | 66 | 11.0 | 3.15 | 40 | 11.0 | 3.15 |
| M4x0.5 | 53 | 13.0 | 4.00 | 73 | 13.0 | 3.15 | 45 | 13.0 | 3.15 |
| M5x0.5 | 58 | 16.0 | 5.00 | 79 | 16.0 | 4.00 | 50 | 16.0 | 4.00 |
| M6x0.75 | 66 | 19.0 | 6.30 | 89 | 19.0 | 4.50 | 50 | 19.0 | 4.50 |
| M7x0.75 | 66 | 19.0 | 5.60 | 89 | 19.0 | 5.60 | 50 | 19.0 | 5.60 |
| M8x1 | 72 | 19.0 | 6.30 | 97 | 19.0 | 6.30 | 60 | 19.0 | 6.30 |
| M8x0.75 | 66 | 19.0 | 6.30 | 97 | 19.0 | 6.30 | 60 | 19.0 | 6.30 |
| M10x1.25 | 80 | 24.0 | 8.00 | 108 | 24.0 | 8.00 | 65 | 24.0 | 8.00 |
| M10x1 | 80 | 24.0 | 8.0 | 108 | 24.0 | 8.00 | 65 | 24.0 | 8.00 |
| M10x0.75 | 73 | 20.0 | 8.0 | 108 | 20.0 | 8.00 | 65 | 20.0 | 8.00 |
| M12x1.5 | 89 | 29.0 | 9.00 | 119 | 29.0 | 9.0 | 70 | 29.0 | 9.00 |
| M12x1.25 | 89 | 29.0 | 9.00 | 119 | 24.0 | 9.00 | 70 | 29.0 | 9.00 |
| M12x1 | 80 | 22.0 | 9.00 | 119 | 24.0 | 9.00 | 70 | 22.0 | 9.00 |
| M14x1.5 | 95 | 30.0 | 11.20 | 127 | 30.0 | 11.20 | 70 | 30.0 | 11.20 |
| M14x1.25 | 95 | 30.0 | 11.20 | 127 | 25.0 | 11.20 | 70 | 30.0 | 11.20 |
| M14x1 | 87 | 22.0 | 11.20 | 127 | 25.0 | 11.20 | 70 | 22.0 | 11.20 |
| M16x1.5 | 102 | 32.0 | 12.50 | 137 | 32.0 | 12.50 | 80 | 32.0 | 12.50 |
| M16x1 | 92 | 22.0 | 12.50 | 137 | 32.0 | 12.50 | 80 | 22.0 | 12.50 |
| M18x2 | 112 | 37.0 | 14.00 | 149 | 37.0 | 14.00 | 90 | 37.0 | 14.00 |
| M18x1.5 | 112 | 37.0 | 14.00 | 149 | 29.0 | 14.00 | 90 | 37.0 | 14.00 |
| M18x1 | 97 | 22.0 | 14.00 | 149 | 29.0 | 14.00 | 90 | 22.0 | 14.00 |
| M20x2 | 112 | 37.0 | 14.00 | 149 | 37.0 | 14.00 | 90 | 37.0 | 14.00 |
| M20x1.5 | 112 | 37.0 | 14.00 | 149 | 29.0 | 14.00 | 90 | 37.0 | 14.00 |
| M20x1 | 102 | 22.0 | 14.00 | 149 | 29.0 | 14.00 | 90 | 22.0 | 14.00 |
| M22x2 | 118 | 38.0 | 16.00 | 158 | 38.0 | 16.00 | 90 | 38.0 | 16.00 |
| M22x1.5 | 118 | 38.0 | 16.00 | 158 | 33.0 | 16.00 | 90 | 38.0 | 16.00 |
| M22x1 | 109 | 24.0 | 16.00 | 158 | 33.0 | 16.00 | 90 | 24.0 | 16.00 |
| M24x2 | 130 | 45.0 | 18.00 | 172 | 35.0 | 18.00 | 95 | 45.0 | 18.00 |
| M24x1.5 | 130 | 45.0 | 18.00 | 172 | 35.0 | 18.00 | 95 | 45.0 | 18.00 |
| M24x1 | 114 | 24.0 | 18.00 | 172 | 35.0 | 18.00 | 95 | 24 | 18.00 |
| M27x2 | 127 | 37.0 | 20.00 | - | - | - | 95 | 37 | - |
| M27x1.5 | 127 | 37.0 | 20.00 | - | - | - | 95 | 37 | - |
| M27x1 | 120 | 25.0 | 20.00 | - | - | - | 95 | 25 | - |
| M28x1.5 | 127 | 37.0 | 20.00 | - | - | - | 105 | 37 | - |
| M28x1 | 120 | 25.0 | 20.0 | - | - | - | 105 | 25 | - |
| M30x3 | 138 | 48.0 | 20.0 | - | - | - | 105 | 48 | - |
| M30x2 | 127 | 37.0 | 20.00 | - | - | - | 105 | 37 | - |
| M30x1.5 | 127 | 37.0 | 20.00 | - | - | - | 105 | 25 | - |
| M30x1 | 120 | 25.0 | 20.00 | - | - | - | 105 | 25 | - |
| M33x3 | 151 | 51.0 | 22.40 | - | - | - | 115 | 51 | - |
| M33x2 | 137 | 37.0 | 22.40 | - | - | - | 115 | 37 | - |
| M33x1.5 | 137 | 37.0 | 22.40 | - | - | - | 115 | 37 | - |
| M36x3 | 162 | 57.0 | 25.00 | - | - | - | 125 | 57 | - |
| M36x2 | 144 | 39.0 | 25.00 | - | - | - | 125 | 39 | - |
| M36x1.5 | 144 | 39.0 | 25.00 | - | - | - | 125 | 39 | - |
Packaging & Shipping
inner packing is plastic box,outer packing is cartons
We can send the goods by sea,air or courier(DHL,TNT,Fedex etc) according to the customer's requirement.
Our Services
we have been the supplier at Alibaba for 9(nine) years.
We always keep our promise and are responsible for the problems if occured after sales.Pls be assured.
Contact Us
- Dezhou Zhongyi Industry And Commerce Co., Ltd.
- Contact nameJack zhao Chat Now
- Phone86-534-2676136
- AddressNo.1-4-8,No.1 Building,Lane 114,East 38 Road, Dezhou, Shandong
