Specifications
CNC chuck with BT,CAT,Din69871,Din2080 standard1)Material:alloy steel
1)size:50,40,30
2)balanced G6.3/12000rpm,G2.5/2000rpm
CNC chuck by BT,CAT,Din69871 standard:
1)Our CNC chuck is CNC tools.
2)As per standard,they include:DIN69871,DIN2080,BT,CAT or morse taper tool holders.
3)As per applcaion,they include:ER collet chuck,morse taper,drill chuck arbors,shell mill arbors,end mill adaptors,power milling chucks etc.
4)For specific details of each item,you can browse our website:www.dzzy.en.china.cn
5)Runout: 0.005mm-0.01mm as per different of cnc chuck
6)Material:High quality alloy steel
7)surface are pricision grounded.
8)Balanced cnc chuck G6.3/12000rm or G2.5/20000rpm is available.
BT standard er collet chuck sizes and specifications is as below:
| model no. | D | D1 | model no. | D | D1 |
| BT30xER16-70 | 28 | 31.75 | BT40xER40-120 | 63 | 44.45 |
| BT30xER20-70 | 34 | 31.75 | BT40xER40-150 | 63 | 44.45 |
| BT30xER25-70 | 42 | 31.75 | BT45xER16-70 | 28 | 57.15 |
| BT30xER32-70 | 50 | 31.75 | BT45xER20-70 | 34 | 57.15 |
| BT30xER40-80 | 63 | 31.75 | BT45xER20-100 | 34 | 57.15 |
| BT40xER16-70 | 28 | 44.45 | BT45xER25-70 | 42 | 57.15 |
| BT40xER20-70 | 34 | 44.45 | BT45xER25-90 | 42 | 57.15 |
| BT40xER20-100 | 34 | 44.45 | BT45xER25-100 | 42 | 57.15 |
| BT40xER20-150 | 34 | 44.45 | BT45xER32-70 | 50 | 57.15 |
| BT40xER25-60 | 42 | 44.45 | BT45xER32-100 | 50 | 57.15 |
| BT40xER25-70 | 42 | 44.45 | BT45xER32-120 | 50 | 57.15 |
| BT40xER25-90 | 42 | 44.45 | BT45xER40-80 | 63 | 57.15 |
| BT40xER25-100 | 42 | 44.45 | BT45xER40-100 | 63 | 57.15 |
| BT40xER25-150 | 42 | 44.45 | BT45xER40-120 | 63 | 57.15 |
| BT40xER32-70 | 50 | 44.45 | BT50xER16-70 | 28 | 69.85 |
| BT40xER32-100 | 50 | 44.45 | BT50xER16-90 | 28 | 69.85 |
| BT40xER32-150 | 50 | 44.45 | BT50xER16-135 | 28 | 69.85 |
| BT40xER40-70 | 63 | 44.45 | BT50xER20-70 | 34 | 69.85 |
| BT40xER40-80 | 63 | 44.45 | BT50xER20-90 | 34 | 69.85 |
packaging way:Inner packing is by plastic box.The outer packing is by cartons.Pallet is available upon the customer's request.
Quality: Each product are inspected durding the production.And then rendomly are selceted for inspection by quality-person.We have exported our goods to around the world and get good feebacks.
Shipment way: We can send the goods by sea,air or couirer(DHL,TNT,Fedex etc) according to the customer's requirement.
Our Services and reputation: we have been the supplier at Alibaba for 8(eight) years.
We always keep our promise and are responsible for the problems if occured after sales.Pls be assured.
