3x3mm Spring Hot Runner Coil Heater
Features
1.voltage and power according to your requirement.
2. various sizes of cross section, including 4.2*2.2mm, 4*2mm, 3.2*1.8mm, 4*4mm, 3.5*3.5mm, 3*3mm and other specificaitons
3.high watt density--25w/sq.cm, low watt density--5w/sq.cm, Temperature:650 degree
4. Material: stainless steel
5.can build in thermocouple according to your requirement.
| Sectional area | 3X3,4.2X2.2,4X2,4X2.7,4X2.5 3.3 X 3.3 3.5 X 3.5 4 X 4,2.2X1.3 |
| Minimum ID |
8mm |
| Sheath Material | SS304,SS310 |
| Insulation Material | High Pure MgO |
| Resistance Wire | Cr20Ni80 |
| Maximum Sheath Temperature | 700°C |
| Die Electrical Strength | 800V A/C |
| Insulation | > 5 M W |
| Dimensional Tolerance | Coil I.D + 0.1 to 0.2mm// Coil Length + 1mm |
| Wattage Tolerance | + 10% (+ 5% Available Upon Request) |
| Voltage | 12V~380V |
| Wattage | 70W~1000W |
| Build-in thermocouple power | without or with J/K thermocouple |
| Sheath's length | 500/1000/1200/1500/2000mm |
| Available sheath | nylon,metal braided,fiberglass ,silicone rubber, kevlar |
| Sheath's color | standard is black,other color is also available |
| Connector | without or with 5 pin xlr,4 pin min xlr connector |
| Connector' color |
silver or fully black
|
The delivery time:
| 10-100pcs | 5days |
| 100-500pcs | 7days |
| more than 500pcs | 10days |
Technical Date
Product show
Order Detail
1. Model Number
2. Voltage & Power
3. Dimension for coil
4. Length of sheath
5. Quanity
Package
--- carton box, wooden case or specified package
Hot runner armoured electric heater
Delivery time
---10 working days if uugent can be negotiable
Shipping method
---Express: UPS, FEDEX, DHL, TNT, EMS, ect
---Air shipping: Please choose your convenient shipping method according your detail requirement.
---Sea shipping: large quntity order
---Normally, it will take around 2--5days from China to destination country.
How to oder products?
---Send inquiry to us or contact with us via email,skype or trademanager
---Confirming the model, specification, price, qty, delivery time and payment method
---Sending invoice to customer
---Customer makes payment and send us receipt
---Arranging production
---Sending products picture to customer after the production is ready
---Shipping products to customer
FACTORY DIRECT SALES coil heater
Hot runner armoured electric heater
Hot runner armoured electric heater
