High Quality Durable Industrial Electric Finned Coiled Air Heater
Features
1.voltage and power according to your requirement.
2. various sizes of cross section, including 4.2*2.2mm, 4*2mm, 3.2*1.8mm, 4*4mm, 3.5*3.5mm, 3*3mm and other specificaitons
3.high watt density--25w/sq.cm, low watt density--5w/sq.cm, Temperature:650 degree
4. Material: stainless steel
5.can build in thermocouple according to your requirement.
| Product name: | High Quality Durable Industrial Electric Finned Coiled Air Heater |
| Minimum order: | 1 Piece |
| Payment: | T/T in advance |
| Port: | Ningbo or Shanghai |
| Delivery time: | 7-15 working days |
| Certification: | ISO9001,CE,PICC |
| Sheath Material | Cr Ni-Steel |
| Insulation Material | MgO |
| Resistance Wire | Ni Cr 80-20 |
| Maximum Sheath Temperature | 700°C |
| Die Electrical Strength | 800V A/C |
| Insulation | >5 M W |
| Thermocouple | J type (Standard) or K type |
| Length Tolerance (Straight) | 5% |
| Wattage Tolerance | + 10% (+ 5% Available Upon Request) |
| Resistance Tolerance | + 10% (+ 5% Available Upon Request) |
| Unheated Length | 35mm (Standard) |
| Dimensional Tolerance | Coil I.D + 0.1 to 0.2mm |
| Coil Length + 1mm |
Technical Date
Product show
Typical applications
Plastic injection molding nozzles
Semiconductor manufacturing and wafer processing
Hot metal forming dies and punches Sealing and cutting bars
Medical, analytical and scientific instruments
Restaurant and food processing equipment
Cast-in heaters
Laminating and printing presses
Air heating
Textile manufacturing
Heating in a vacuum environment
Order Detail
1. Model Number
2. Voltage & Power
3. Dimension for coil
4. Length of sheath
5. Quanity
240V electric nail flat coil heater with 5 pin xlr plug
Package
--- carton box, wooden case or specified package
Delivery time
---10 working days if uugent can be negotiable
Shipping method
---Express: UPS, FEDEX, DHL, TNT, EMS, ect
---Air shipping: Please choose your convenient shipping method according your detail requirement.
---Sea shipping: large quntity order
---Normally, it will take around 2--5days from China to destination country.
240V electric nail flat coil heater with 5 pin xlr plug
How to oder products?
---Send inquiry to us or contact with us via email,skype or trademanager
---Confirming the model, specification, price, qty, delivery time and payment method
---Sending invoice to customer
---Customer makes payment and send us receipt
---Arranging production
---Sending products picture to customer after the production is ready
---Shipping products to customer
240V electric nail flat coil heater with 5 pin xlr plug
240V electric nail flat coil heater with 5 pin xlr plug
1.Question:I am not find the my demand on your web.
Answer:Pls kindly send email to us,most heaters are customer made.
2.Question:How many engineer in your company?
Answer:About 5-10people.
3.Question:Do you provide customed drawing?
Answer:Yes,we provide drawing after we know all the information of heater.
4.Question:Who is your designated supplier?
Answer:Such as Sinopec and China Oil Group ect
hu 240V electric nail flat coil heater with 5 pin xlr plug
