Help CenterJOWELL&Synthetic Fibre F7 Housing Bag Filter
Related Products
-
ISO SGS CE ROHS JOWELL& Non-woven F7 Machinery Bag FilterUS$ 3.36 - 24.96MOQ: 50 Pieces -
F5 Medium Effiency Bag Air FilterUS$ 3.36 - 24.96MOQ: 50 Pieces
-
Zhuowei White Color Non-woven Pocket Air FilterUS$ 3.38 - 25.68MOQ: 50 Pieces
-
F6 Various High Quality Air Conditioning Industrial Air FiltersUS$ 3.38 - 25.68MOQ: 50 Pieces
-
F5 Medium Efficiency Pocket Air Filter For Dust CollectionUS$ 3.38 - 25.68MOQ: 50 Pieces
air filter pocket filter bag filter g4 f5 f6 f7 f8
Product Ranges: We manufacture a wide range of Air filters and Cleanroom products such as
- Pre-Filters / pleated filters with efficiencies available of G1 ~ G4 (EN779 Europe Standard)
- Bag/Pocket Filters with efficiencies available of F5 ~ F8 (EN779 Europe Standard)
- Medium efficiency V-bank Filters with large airflow.
- Deep pleated HEPA Filters with cardboard separator or aluminum separator, and frame available with wooden, galvanized sheet and aluminum alloy.
- High temperature resistant HEPA Filters used under 250~350 C degree
- Mini Pleated HEPA Filters with efficiencies of H13~U17 (EN1822 Europe Standard)
- Ceiling Ducted HEPA Modules ( Two type: side air supply and top air supply)
- Disposable HEPA Filter Modules
- Fan Filter Unit ( FFU)
- Pass Box
- Laminar Airflow Clean bench
- Air Shower and Cargo Shower
- Other Accessories
Product Applications:
- Pharmaceuticals; microelectronics,
- food &beverage; laboratories;
- commercial buildings; museums;
- schools; chemicals; Healthcare;
- Airport; Shopping Mall ; Hospitals; clinic…etc
| Ln | Dimensions(mm) | Rated Air Flow M3/h | Bags | Inital resistance | Midia | Efficiency % EN779 | Frame | |
| F5 BAG Filter | ||||||||
| 1 | 595x595x600 | 3200 | 6 | 45pa | F5 non-woven fabric | 40%-50% Dust-spot | F5 | Aluminum Alloy Galvanized Sheet |
| 595x595x600 | 2700 | 5 | ||||||
| 595x495x600 | 2500 | 6 | ||||||
| 495x295x600 | 1600 | 6 | ||||||
| 495x295x600 | 1300 | 4 | ||||||
| F6 BAG Filter | ||||||||
| 2 | 595x595x600 | 3200 | 6 | 45pa | F6 non-woven fabric | 60%-70% Dust-spot | F6 | Aluminum Alloy Galvanized Sheet |
| 595x595x600 | 2700 | 5 | ||||||
| 595x495x600 | 2500 | 6 | ||||||
| 495x295x600 | 1600 | 6 | ||||||
| 495x295x600 | 1300 | 4 | ||||||
| F7 BAG Filter | ||||||||
| 3 | 595x595x600 | 3200 | 10 | 55pa | F7 non-woven fabric | 80%-85% Dust-spot | F7 | Aluminum Alloy Galvanized Sheet |
| 595x595x600 | 3000 | 8 | ||||||
| 595x495x600 | 2700 | 10 | ||||||
| 495x295x600 | 1600 | 10 | ||||||
| 495x295x600 | 1300 | 8 | ||||||
| F8 BAG Filter | ||||||||
| 4 | 595x595x600 | 3200 | 10 | 55pa | F8 non-woven fabric | 90%-95% Dust-spot | F8 | Aluminum Alloy Galvanized Sheet |
| 595x595x600 | 3000 | 8 | ||||||
| 595x495x600 | 2700 | 10 | ||||||
| 495x295x600 | 1600 | 10 | ||||||
| 495x295x600 | 1300 | 8 | ||||||
Features:
F5 medium efficiency bag filter is available in efficiencies of 40-50% on 1-5 micron particles; large air flow, low resistance; high dust holding capacity;Be reusable after being washed repeatedly.
This product is used for fine filtration in ventilation system, secondary filtration in clean-room and primary filter for HEPA filter
1.Galvanized or Aluminum frame. Between each pocket has a metal stick to make frame more firm, and the separation material of each pocket can avoid the filter over expanded under the pressure
2.Ultrasonic sealing make the filter more strong and not easy to broke
3. Adopting fine synthetic fiber instead of some fiberglass material
4.Large dust holding capacity, long working life
Compectitive Advantage:
This product is used for fine filtration in ventilation system, secondary filtration in clean-room and primary filter for HEPA filter
1.Galvanized or Aluminum frame. Between each pocket has a metal stick to make frame more firm, and the separation material of each pocket can avoid the filter over expanded under the pressure
2.Ultrasonic sealing make the filter more strong and not easy to broke
3.Adopting fine synthetic fiber instead of some fiberglass material
Model |
Dimensions(mm) Wi×H×D |
Number of pockets |
Rated air flow |
Initial resistance |
Efficiency % EN779 |
Material |
||
Frame |
Filter media |
|||||||
F5 |
595×595×600 595×595×600 595×495×600 495×295×600 495×295×600 |
6 5 6 6 4 |
3200 2700 2500 1600 1300 |
45 |
40-50 colorimetry |
F5 |
Aluminum alloy/galvanized sheet metal |
F5 non-wove |
Packing Details : Carton ,woden cases.
Delivety Time :Within in 7 days after payment.
1. Are you trading company or Manufacturer ?
We are the factory.
2.What's your mainly products ?
We are the high-tech enterprise which specializes in design.manufacture,sale ,installnation and inspection of air filters and
purification equipments.
3.What about the payment terms ?
We can provide T/T,PAYPAL,WEST UNION.
4. How long your delivey time ?
Delivery will be within 7 days after payment.
Welcome to visit our factory !
Hope to coooperate with you in the further future !
