Dust Removal Air Shower Installed in The Inlet of Clean Rooms

FOB Price

Negotiable / Set

1 Set(Min.Order)

Port Shenzhen
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Guangdong, China
Brand Name	Jowell	Model Number	AS-1600
Voltage	AC 1 phase 220V 50/60Hz	Power(W)	20W
Dimension(LWH)	160020501000mm	Certification	ISO9001
Warranty	five years	After-sales Service Provided	No overseas service provided

Product Description

Specifications

Dust Removal Air Shower Installed in The Inlet of CleanRooms
Photoelectric Sensor Automatic Blow
Stainless nozzles

Dust Removal Air Shower Installed in The Inlet of Clean Rooms

The materials for case can be chosen from all cold rolled steel plate with powder coated, stainless steel inside and cold rolled steel plate with powder coated outside , and all stainless steel (SS201 or SS304; thickness: 1.0 mm or 1.2 mm).

The air shower time is adjustable from 1-99 seconds, compact and sound in structure. An air shower passage can be made up of several air showers.

Features:

1.Photoelectric sensor, automatic blow

2.Electronically interlocked with double stainless door

3.Stainless nozzles

4. Audio system

5. With Auto, Stop, Manual, Emergency Stop function keys

6. An Emergency Stop push button: will override the operating cycle to release the door locks immediately

7. Custom sizes are possible

Model, dimensions and parameters:

Model	J-AR-1000	J-AR-1500	J-AR-2000	J-AR-3000

External Dimension (WxDxH)mm	1240x1000x2050	1240x1500x2050	1240x2000x2050	1240x3000x2050
Internal work area dimension(WxDxH) mm	800x860x1930	800x1360x1930	800x1860x1930	800x2860x1930
HEPA filter dimensions	600x600x69 @2 Pieces	915x600x69 @2 Pieces	600x600x69 @4 pieces	600x600x69 @6 pieces
No of Nozzles	12( two sides)	18 (two sides)	24 (two sides)	36 (two sides)
Air shower time	0~99s Adjustable
Fan Run(r/m)	2800	2800	2800	2800
Nozzle diameter	38mm
Wind Speed	15~20m/s
Noise	62 db(A)
Filter efficiency	≥99.99% @0.3μm
Power	3N 380V 50/60Hz
Max.Power (w)	1100W	1100W	2200W	3300W
Approximate Weight	200kgs	300kgs	400kgs	600kgs
Person(s) per cycle	1 person	2 persons	3 persons	4~5 person
Cabinet Construction	1-Main Body and Internal Work Zone are Coated Iron Sheet
	2-Main Body is Coated Iron Sheet and Internal Work Zone is Stainless Steel
	3-Main Body and Internal Work Zone are Stainless Steel
