Solar Hybrid Inverter PCU UPS 10kVA Solar Home Backup Device for Blackout and Solar Feed in 10kVA

Description

Specification

About Technology

Type of Inverter

TRUE HYBRID (Dual Input Source DC Type)

Nominal Rating

As Per Annexure

Max PV input Power

[50.0 Amp x (Specified Vdc x 1.5)] Wp

Control type

MOSFET

Power Control

PWM

Output Phase

1 Phase

DC current isolation

By Inbuilt Transformer

Grid Terminal

Appropriate rating terminal out for plug-IN

Solar Terminal

Power Terminals 80 Amp.

Operating Parameters

Solar Input Voltage range

[1.083 x Specified Vdc] to [1.666 x Specified Vdc] V

Max Solar DC Input Voltage

[1.83 x Specified Vdc] V

Max Dc Solar current

25 A on max voltage

Input Grid AC voltage Range

UPS:-180 - 260 V, INV:- 100 - 280 V

Input Grid AC frequency Range

50 Hz ± 1.0 Hz

Output Voltage @ Batt. Full Charge

200 - 220 VAC

Wave Out type

pure sinusoidal

Total harmonic distortion (THD)

< 3 % for Resistive Load

Output frequency

50 Hz (±1.0 Hz)

Charging Method

Active Advance Battery Voltage dependent with multi controls for ripple free Charging

No-Load Loss

As Per Annexure

Overload Capacity at <= 120 %

5 sec

Overload Capacity at > 200 %

Immediate trip

Peak efficiency

≥ 85 %

Working Conditions

Temperature : 0 deg C to + 45 deg C, Humidity≥: 95 %

Noise emissions (dBA)

< 50 dB at 1mtr

Maximum operating altitude

1000 mtr

Protections

Surge Protection

Available

Reverse polarity protection for Battery

Available

Reverse polarity protection Solar

MOSFET based

Battery Protection

Automotive Fuse/ MCB (Type C curve)

Grid Protection

MCB (Type C curve)

Load Protection

Automotive Fuse/ MCB (Type C curve)

Internal fault protections:-

1.          Over temperature protection

Available

2.          Over load protection.

Available

3.          Short circuit protection.

Available

DC Under voltage protection Per Batt.

10.4 V +/- 0.3V

AC Under / Over voltage protection

UPS:-180 - 260 V, INV:- 100 - 280 V (With 10 V Hys.)

Audio warning/alarms

BUZZER with Back Light Color Change feature

Emergency off button

Push to OFF

Display on front panel

Customized LCD Display.
