Specifications
hard alloy saw tips1.Good abrasive resistance
2.Long service life
3.Good heat & corrosion resistance
Zhuzhou Tongda Carbide Co., Ltd. founded in 2001, a professional tungsten carbide manufacturer over 13 years experience in Zhuzhou City, we produce hard alloy saw tips in different sizes and qualities. We accept orders of all types of special products according to customers' specific requirements.
Friendly Remind:
The price of hard alloy saw tips will be adjusted by the specific specifications, tolerance, surface treatment as well as the order quantity, if you interested in our product, welcome to call me on the line or mail to me: thanks!
ATTN: Carlina Peng
Tell: 86-757-2816 4567
Skype:
|
ISO Range |
WC% | Co% | Grain size | Density | Hardness HV30 | HRA |
Transverse Rupture |
| K10 | 94% | 6% | 0.8 μ.m | 14.8 g/cm3 | 1500 N/mm2 | 90.8 | 2400 MPa |
| K05-K10 | 92% | 8% | 0.5 μ.m | 14.8 g/cm3 | 1800 N/mm2 | 93.5 | 3800 MPa |
| K05-K15 | 0.6 μ.m | 14.85 g/cm3 | 1750 N/mm2 | 93.1 | 3200 MPa | ||
| K30 | 92% | 8% | 0.8 μ.m | 14.7 g/cm3 | 1450 N/mm2 | 90.5 | 2600 MPa |
| K20-K30 | 90% | 10% | 0.5 μ.m | 14.35 g/cm3 | 1700 N/mm2 | 92.5 | 4000 MPa |
| K20-K30 | 90% | 10% | 0.6 μ.m | 14.5 g/cm3 | 1600 N/mm2 | 91.8 | 4100 MPa |
| K20-K30 | 90% | 10% | 0.7 μ.m | 14.5 g/cm3 | 1550 N/mm2 | 91.5 | 3800 MPa |
| K20-K30 | 90% | 10% | 0.8 μ.m | 14.4 g/cm3 | 1550 N/mm2 | 91.5 | 3500 MPa |
| K30-K40 | 88% | 12% | 0.5 μ.m | 14.2 g/cm3 | 1700 N/mm2 | 92.5 | 4300 MPa |
| K50 | 85% | 15% | 0.7 μ.m | 14.0 g/cm3 | 1150 N/mm2 | 87.5 | 2800 MPa |
— We're a mature manufacturer of tungsten carbide products who with over 13 years experience.
— With the strongly & professional technical team's support, who engaged in carbide industry over than 20 years.
— Using HIP sintering technology, which with good densification, high hardness & excellent wear resistance. etc. |
— Using German Import antomatic extrusion equipments, the pressure can be adjusted as per the specific requirements. Custom sizes are available (L ≤ 1.4m) |
|
|
— Using 100% virgin fine grain tungsten powder & located in one of the world’s five biggest cemented carbide base -Zhuzhou City.
>> We use the main delivery companies as belows:
hard alloy saw tips
