4.6KV 10KA ZnO Varistor
Negotiable
/ Piece
1000 Pieces(Min.Order)
- 10000 Piece / Pieces per Month
- Tianjin or Shanghai
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Hebei, China | Brand Name | FaYun | |
| Model Number | D4 | Type | Varistor | |
| Technology | Metal Oxide | Package Type | Other |
Product Description
Specifications
4.6KV 10KA ZnO Varistor1.Voltage:4.6-5.5KV
2.Diameter:50-58mm,Height:24mm
3.Current<10KA
4.Used in arrester, insulator,
4.6KV 10KA ZnO Varistor
Usage:Used in arrester and insulator,Distribution,power station,Electric machinery
Metal Oxide Varistor is the core of the arrester.
Metal Oxide Varistor is the core of the arrester, which main component is Zinc Oxide and with a small quantity of bismuth Oxide, fluoride oxide, manganous carbonate, antimony oxide and other gleam of additive and made with high temperature.
| Modle | SIZE | Valtage at 1mA D.C. KV | Min. leakage current(A) at 75%U 1mA ≤u A | Ratio of votage of Residual voltage at 8/20us ligtning impulse and 1mA D.C. | current impulse withstand capability | |||||
| Outside Diameter | Inside Diameter | Height mm | 2ms recangular A | 4/10us high current KA | ||||||
| mm | mm | 5KA | 10KA | 20KA | ||||||
| D5 | 50±0.5 | 24±0.5 | 4.6-5.5 | 15 | 1.65 | 1.75 | 450 | 100 | ||
| 52±0.5 | 24±0.5 | 4.6-5.5 | 15 | 1.63 | 1.74 | 500 | 100 | |||
| 58±0.5 | 24±0.5 | 4.6-5.5 | 15 | 1.62 | 1.71 | 600 | 100 |
