Negotiable
MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
FaYun
Model Number:
FZSW
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin or Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Polymeric Insulator,pin Type,suspension,post InsulatorNegotiableMOQ: 1000 Pieces -
Pin Type InsulatorNegotiableMOQ: 100 Pieces
-
Post Insulator 750KV Coomposite InsulatorNegotiableMOQ: 100 Pieces
-
Composite Post InsulatorNegotiableMOQ: 100 Pieces
-
Insulator/post Insulator/suspension Insulator/pin Type InsulatorNegotiableMOQ: 100 Pieces
Place of Origin
Hebei, China
Brand Name
FaYun
Model Number
FZSW
Type
Insulator
Material
Other, Composite Polymer, composite polymeric
Application
High Voltage
Specifications
post insulator1.Height:70-2300mm
2.1min Power frequency withstand Voltage:68-560
3.Creepage:385-4030
4.rated voltage:12-252
post insulator
Usage:The product are suitable for the innovation of urban electical network where it can increase the voltage and transport the electricity effectively by using the narrow street.And it can reduce the necessary height of the pole/tower.Due to it’s high stength of bending,it will comepletely avoid the crack case that happened on porcelain crossarm.Moreover,it can be well pollution resistan.
| Insulator Mode | Rated Voltage kV | Rated Bending machinery Load of no less than KN | Total Height mm | Minimum nominal Creepage Distance mm | 1 min Power -frequency withstand Voltage≥kV | Lightning impulse withstandVoltage ≥kV | ||
| Dry | Wetlands | |||||||
| FZSW-12/6 | 12 | 6 | 130 | 385 | 68 | 50 | 125 | |
| FZSW-40.5/8 | 40.5 | 8 | 445 | 650 | 108 | 95 | 230 | |
| FZSW-72.5/6 | 72.5 | 6 | 70 | 1160 | 200 | 185 | 410 | |
| FZSW-126/8 | 126 | 8 | 4 | 1220 | 2015 | 280 | 230 | 550 |
| FZSW-126/12.5 | 126 | 12.5 | 6 | 1220 | 2015 | 280 | 230 | 550 |
| FZSW-252/6 | 252 | 16 | 6 | 2300 | 4030 | 560 | 395 | 1000 |
