CE Certficated Double Heads Size 60*90cm Economical Industrial A2 uv Led Printing Machine for Various Media

CE Certficated Double Heads Size 60*90cm Economical Industrial A2 uv Led Printing Machine for Various Media thumbnail-1
CE Certficated Double Heads Size 60*90cm Economical Industrial A2 uv Led Printing Machine for Various Media thumbnail-2
CE Certficated Double Heads Size 60*90cm Economical Industrial A2 uv Led Printing Machine for Various Media thumbnail-3
CE Certficated Double Heads Size 60*90cm Economical Industrial A2 uv Led Printing Machine for Various Media photo-1
CE Certficated Double Heads Size 60*90cm Economical Industrial A2 uv Led Printing Machine for Various Media photo-2
CE Certficated Double Heads Size 60*90cm Economical Industrial A2 uv Led Printing Machine for Various Media photo-3
US$ 1 - 7,900 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Other, Flatbed Printer, UV flatbed printer
Place of Origin:
Shanghai, China
Contact Supplier Request Quote Chat Now
Hangzhou KingMa Ware Trading Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Plate Type Other, Flatbed Printer, UV flatbed printer
Place of Origin Shanghai, China
Brand Name kmajet
Model Number KMA6090
Usage Bill Printer, Card Printer, Label Printer, Card Printer, Cloths Printer, Paper Printer, Tube Printer
Automatic Grade Automatic
Voltage 110V50HZ / 220V50HZ
Gross Power 58000W
Dimensions(L*W*H) 4215*2100*1330mm
Weight 80kgs
Certification CE, SASO, SGS
After-sales Service Provided Engineers available to service machinery overseas

 CE certficated double heads  size 60*90cm economical industrial A2 uv led printing machine  for various media





 A2 uv flatbed printer Specification:     TECHNICAL SPECIFICATION
 Printhead:  EPSON
 Resolution: 600,900,1200,2400 dpi
 Color:  four colors, six colors, white color and varnish for option (CMYK+WHITE/VARNISH)
 Printing thickness: 0-100 mm
 inks curing system: UV LED lamp curing system
 Air flatbed system:  air draft flatbed system available
 Ink type:  UV LED curing inks
 Printing medias: glass, Acrylic, Ceramic, Metal, Paper, Wood,Leather,PVC, PP ,PE
 Lifetime: 2 years outdoor, 8 years indoor
 Ink cartridge capacity: 2.5 L  Automatic check capacity
 Printing software: Photoprint/Montop
 Computer operation system: Window 7 32/64 bit RAM≥8G
Temperature: 18-45 ℃
Max power: 5.8KW, AC 50HZ, 220v(±10%), 15A
Support image format: TIFF, JPEG, EPS, PDF
Printer size: (L*W*H) 4215*2100*1330mm
Packing size: (L*W*H) 4320*2250*1625mm

 CE certficated double heads size 60*90cm economical industrial A2 uv led printing machine for various mediaCE certficated double heads size 60*90cm economical industrial A2 uv led printing machine for various mediaCE certficated double heads size 60*90cm economical industrial A2 uv led printing machine for various mediaCE certficated double heads size 60*90cm economical industrial A2 uv led printing machine for various media



 A2 uv flatbed printer Features:

  • UV curing patent technology, and cooperate with the imported high quality cooling water system,, to ensure the high light efficiency, 3d embossed effect, dry immediately,  good curing effect

  • Refit the original epson R2000 printer, adhering to the high precision, high speed function

  • Pressure Type Ink Supply ,sealed ink bottle

  • Grating inside ,reduce damage and polution. Square shaft,make sure high precision print and avoid print slower after long time used

  • Firmed and Thick flatbed ,can print heavy material,glass surface easy to clean

  • Grating inside , reduce damage
  • 3D embossed effect,Maintop software,print white and colored together
  • Epson DX7 print head,greatly save cost
  • Square shaft, make sure high precisioi printing and avoid  print slower after using long time







UV printer Cooling System:

LED UV is water cooling system,lower noise, lighter weight,smaller damage when printing,keep motor life longer.
Air cooling system: big noise, heavy body damage printer easy and motor life time is short







What Material can uv led flatbed printer small Print On?



Direct to print material as below

Can print on metal, glass, crystal, tile ceramic, acrylic, phone case, PVC, PU, Leather, Silicone,Wooden and so on



Pre-coating print material as below

Metal,glass,crystal,tile ceramic, acrylic, wooden, need pre-coating before printing



UV Cure

No matter what material printed on ,will dry immediately



Cost

The cost of ink is about RMB 0.1 for one phone case



Speed

The speed for printing 1 iphone 5s case about 1-2min



CE certficated double heads size 60*90cm economical industrial A2 uv led printing machine for various mediaCE certficated double heads size 60*90cm economical industrial A2 uv led printing machine for various mediaCE certficated double heads size 60*90cm economical industrial A2 uv led printing machine for various media CE certficated double heads size 60*90cm economical industrial A2 uv led printing machine for various media





Uv ink features:



l UV ink pigment particle diameter is less than 1 micron,it does not contain volatile organic solvents, the viscosity is very low,and it without excitant odour, we can ensure that the ink jet printing no plug nozzle phenomenon in the process, after a six-month high temperature storage test, no pigment, sinking, layered anomaly.
lLED UV ink is dry immidiately when sprayed, it can be used with the current market of various types of nozzle UV plate prints match.
lLED is suitable for UV ink jet printing metal, glass, ceramics, PC, PVC, ABS and other materials.After curing ink layer hardness, has strong adhesion to scrub resistance, solvent resistance, high gloss.
lUV ink have 6 colors:C,M,Y,K,W.W,the lightfast is 7-8 level,1L/barrel ,Applicable to the epson nozzle dedicated LED UV flat-panel printers

CE certficated double heads size 60*90cm economical industrial A2 uv led printing machine for various media



uv led flatbed printer small packing list





  • Printer
  • printer software driver and manual
  • power cable 1.8mm
  • printer software USB key
  • USB cable 1pcs
  • spare ink dampers 2pcs
  • syringe



UV printer package :



CE certficated double heads size 60*90cm economical industrial A2 uv led printing machine for various media



CE certficated double heads size 60*90cm economical industrial A2 uv led printing machine for various mediaCE certficated double heads size 60*90cm economical industrial A2 uv led printing machine for various media
