Petroleum Oil Composite hose
Hose Assemblies
Due to the often hazardous conveyance used it is recommended that composite hose should only be used with properly fixed fittings. Composite hoses are normally fitted by the wire whipped method or by external crimp. All hoses have a 4 to 1 safety factor.
Testing
All hose assemblies must be pressure tested hydrostatically to one and a half times the maximum recommended working pressure and electrically tested to confirm continuity per AS2683/AS2594/AS1180.
Fittings
A wide range of fittings can be supplied such as Camlocks, BSP fittings, flanges etc.
Composite Hose Handling Guide
Plasticoat composite hoses are made from quality materials. Their inner films and fabrics provide optimum chemical resistance. Protected with the PVC impregnated outer covers, Plasticoat composite hoses provide the strength and versatility for all petrol and chemical applications.
Rope Lagging
All hoses can be supplied with rope lagging. It is necessary to specify at time of ordering. Polypropylene rope is used as lagging. Lagging insulates and protects the hose from abrasion.
Petrolmaster Standard Hose- green with yellow stripe
APPLICATIONS: Light weight, flexible hose designed for suction and delivery of petroleum based products.Suitable for road and rail tankers. Internal Wire - galvanised steel. External wire - galvanised steel.
Petrolmaster Heavy Duty hose- black
APPLICATIONS: Used for ship to shore and general purpose heavy duty applications conveying petroleum products. Suitable for heavy duty discharge for road and rail tankers, docks, ship to shore. Internal Wire - galvanised steel. External wire - galvanised steel.
APPLICATIONS
Manufactured from polyester film and fabric designed for high temperature operation, this hose is ideal for the transfer of hot bitumen via gravity, suction or pressure. This hose is suitable for use with bitumen up to 180C”. It is ideally suited for road tanker loading and discharge, in Plant transfer, spraying and spray bar applications. This hose is also suitable for conveying high aromatic content fuels. Internal Wire- Galvanised Steel External wire - Stainless Steel
Note:
- This hose is not recommended for use close to direct external radiant heat as the cover is not flame retardant.
- Hoses should be flushed with diesel or kerosene after use. Cleaning with steam or direct external heat is not recommended.
