Home > Industrial Equipment & Components > Engine & Part > Engine Parts > Marine Type I Rubber Fender Fender

Marine Type I Rubber Fender Fender

Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Chongqing, China

Brand Name:

TUF

Model Number:

Contact Supplier Request Quote Chat Now

Chongqing Perpetual Import And Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Chongqing, China

Brand Name TUF

Model Number TR

Part Other, Rubber Fender

Type I Rubber Fender/ marine fender

Features

1. Lease impact strength, high absorption of energy

2. easy to be installed and maintenance due to simple shape

3. It can be widely used and it will be suitable to any size of the ship or wharf.

4. It can be absorbed most of the impact energy of pitching and rolling when

ship alongside

Advantage

1.larger rated compression, higher energy absorb, Fender energy absorption raise

10% or so than super arch type rubber fender.

2 Fender installation flexible, it can adopt crosswise, longitudinal, combination etc style.

it can meet the requirement of different docks.

3 Front panel set in front of fender, It can lower the surface pressure of vessel side

board.

4 UHMW-PE set in front of panel, it can lower friction factor between vessel and fender,

lower the shear strength while vessel berthing, and raise utility of fender life.

5 After fender adopt combination style, slant compression performance changeable

very little.

The major characteristics of Unit Element Fender include:

1. Good energy absorption to reaction force ratio (E /R);

2. High energy absorption per weight of rubber;

3. Good angular performance and high efficiency;

4. Modular and compact design with small footprint;

5. Vertically and horizontally mounted elements may be combined in one system;

6. Wide range of sizes.

Application:

1.high suitable for the large wharf

2.Rubber fender is a kind of protection facility suitable to be installed on the wharf.

It can be absorbed the energy upon ship alongside and reducing the impact strength

to ensure the structure of vessel and wharf harmless.

3.Rubber fenders are the simplest and most appropriate solution for a wide range of

applications in areas used as wharf moorage, guaranteeing long lasting performance

and requiring no maintenance. Their innovative design assures high performance, fast

and easy moorage, and maximum ship stability even in situations of extreme stress,

thanks to the vulcanized steel plates placed on the base and completely covered with

rubber.

Measures:

specification	H	A	B	C
I300H	300	94	94	47
I400H	400	125	124	63
I500H	500	158	158	87
I550H	550	172	170	87
I600H	600	188	199	87
I750H	750	235	230	118
I800H	800	250	240	129
I1000H	1000	322	310	162
I1250H	1250	451	388	202
I1400H	1400	454	454	228
I1600H	1600	500	480	257

Performance list

specification	High reaction force		Standard reaction force
specification	(KN) (KN-M)		(KN)	(KN)
I300H	160	22	110	15
I400H	210	39	150	27
I500H	265	61	187	43
I550H	294	75	206	52
I600H	320	89	224	62
I750H	400	137	282	96
I800H	428	157	299	110
I1000H	535	245	374	172
I1250H	668	383	467	268
I1400H	775	516	543	361
I1600H	855	628	599	440
