Help CenterFRP Marker Buoy
Related Products
Specifications
FRP marker buoySpecifications for FRP marker buoy
The weight is 30~50% of the same type steel buoy
Little sea creatures adhered
Easy cleaning & long time maintenance of surface
Characteristic:
The item made by FPR materials with resilient closed cell polyethylene foam fill up and stainless steel skeleton
1. the buoy made by new materials, Easy assembly, Light weight, Convenient transportation and apply in sea or river.
2. The main body is made by FRP materials with Resilient closed cell polyethylene foam fill up. The new material has a better ability in Anti-collision and Sustainable resistance to crashing and not damaged. It also has a better ability in buoyancy.
3. The buoy made by the new material will be good in resisting corrosion, High temperature, Strong sunlight, Marine life.
4. The most important is maintenance free for this type of new material buoy.
Specifications for FRP marker buoy :
1. Wind resistance: 12 levels
2. Anti-clutter sea: 9 levels
3. Working temperature: -40~60degrees Celsius
4. Service life: 10
5. Operation areas:coastal harbor, inland river,rocks,reef and bank etc.
Specification & Technical Parameter of FPR BUOYS For Reference:
Type |
TUF-D3.0 |
TUF-D2.4 |
TUF-D1.8 |
TUF-D1.5 |
TUF-D1.2 |
||
Diameter |
3000mm |
2400mm |
1800mm |
1500mm |
1200mm |
||
Height of Buoy |
7350mm |
6540mm |
4450mm |
3140mm |
2620mm |
||
Depth |
3400mm |
3050mm |
2050mm |
1350mm |
1200mm |
||
Focal Height |
4250mm |
3800mm |
2710mm |
2080mm |
1710mm |
||
Weight of Buoy |
2450 kg |
1650 kg |
850 kg |
380 kg |
270 kg |
||
Weight of Configuration |
500 kg |
300 kg |
300 kg |
200 kg |
100 kg |
||
Lantern |
155mm |
155mm |
155mm |
90mm |
90mm |
||
Power Source |
Major |
Sea water power source |
Silicon solar battery |
||||
Minor |
Zinc air battery or silicon solar battery |
Zinc air battery |
|||||
Range |
>6 mil |
>6 mil |
>6 mil |
>4 mil |
>4 mil |
||
Water Depth |
13-40m |
13-40m |
5-20m |
5-15m |
5-10m |
||
