Specifications
navigation light buoyDiameter size from 1.5m to 3m, made of steel, used at shallow water area/ navigation light buoy .
Model |
HF1.5-D2 |
HF1.8-D2 |
HF2.4-D2 |
HF3.0-D2 |
Diameter |
1500mm |
1800mm |
2400mm |
3000mm |
Superstructure Height |
3204mm |
4270mm |
5700mm |
7000mm |
Focal Height |
1620mm |
2940mm |
3980mm |
4175mm |
Recommend Lantern |
155mm lantern |
|||
Power Source |
Optional |
|||
Draft |
1100mm |
1330mm |
1720mm |
1650mm |
Water Depth Range |
<10m |
<20m |
<30m |
<40m |
Weight |
1530kg |
2410kg |
5710kg |
5000kg |
Fitting Chain Characteristics | ||||
Saddle Chain |
Φ22mm×2.76m-1set |
Φ28mm×2.72m-1set |
Φ34mm×5.26m-1set |
Φ37mm×5.24m-1set |
Main Chain |
Φ22mm×27.5m-1set |
Φ28mm×27.5m-1set |
Φ34mm×27.5m-1set |
Φ37mm×27.5m-1set |
End Shackle |
Φ32mm-4pcs |
Φ39mm-4pcs |
Φ48mm-4pcs |
Φ52mm-4pcs |
Short Chain |
Φ22mm×4.5m-1set |
Φ28mm×4.5m-1set |
Φ34mm×4.5m-1set |
Φ37mm×4.5m-1set |
Link Shackle |
Φ28mm-1pcs |
Φ36mm-1pcs |
Φ44mm-1pcs |
Φ48mm-1pcs |
Sinker Weight |
1.5T |
2T |
3T |
4T |
