Specifications
Anchor Chain:1. High Strength Steel Bar.
2. Size: 12.5mm to 162mm.
3.U2 U3 RQ3 RQ4 Grade.
4. High Quality, Fast Deliv.
U2 GRADE STUD LINK MARINE ANCHOR CHAIN/ STUD LNK SHIP ANCHOR CHAIN
1. Size from 12.5mm to 200mm ,we also can produce according to your requirement .
2.Material: alloy steel, generally including CM390, SM490, CM690, or aoording to your requirement
3.Grade :U1,U2&U3
4.Surface treatment: self color, black painted, zinc galvanized, hot dip galvanized or according to customer's requirement.
5.The tension beak load conforms to National Standard.
6. Studless anchor chains. Specification: 12.5-200mm, mainly adapt to vessels, fish net tenesmus, mine, municipal engineer, new established garden decoration
ABS(America), LR(Britain), BV(France), GL(Germany), NK(Japan), KR(Korea), DNV(Norway), RINA(Italy),CCS(China).
Specification of Studless Link Anchor Chain:
|
Dia. (mm) |
Outside Length (mm) |
Outside Width (mm) |
U2 | U3 |
Weight (KG/27.5M) |
||
|
Proof Load (KN) |
Breaking Load (KN) |
Proof Load (KN) |
Breaking Load (KN) |
||||
| 16 | 96 | 56 | 66.2 | 132.3 | 92.42 | 184.83 | 138.14 |
| 17.5 | 105 | 61.25 | 78.89 | 157.78 | 110.55 | 221.1 | 165.8 |
| 19 | 114 | 66.5 | 93.6 | 187.2 | 130.32 | 260.64 | 194.9 |
| 20.5 | 123 | 71.8 | 108.64 | 217.27 | 151.7 | 303.42 | 227.13 |
| 22 | 132 | 77 | 125.4 | 250.9 | 174.4 | 349.4 | 262.29 |
| 24 | 144 | 84 | 149.9 | 298.9 | 207.9 | 415.8 | 312.26 |
| 26 | 156 | 91 | 175.4 | 350.8 | 244 | 488 | 366.76 |
| 28 | 168 | 98 | 203.8 | 406.7 | 283 | 566 | 423.36 |
| 30 | 180 | 105 | 234.2 | 467.5 | 324.9 | 649.8 | 486.85 |
| 32 | 192 | 112 | 265.6 | 531.2 | 369.6 | 739.3 | 554.7 |
| 34 | 204 | 119 | 299.9 | 599.8 | 417.3 | 834.6 | 628.08 |
| 36 | 216 | 126 | 336.1 | 672.3 | 467.8 | 935.7 | 701.54 |
| 38 | 228 | 133 | 374.4 | 748.7 | 521.3 | 1042.5 | 781.92 |
| 40 | 240 | 140 | 414.5 | 829.1 | 577.6 | 1155.2 | 861.17 |
| 42 | 252 | 147 | 457.7 | 915.3 | 636.8 | 1273.6 | 950.94 |
| 44 | 264 | 154 | 502.7 | 999.6 | 698.9 | 1398 | 1053 |
| 46 | 276 | 161 | 548.8 | 1097.6 | 763.9 | 1527.8 | 1142 |
| 48 | 288 | 168 | 597.8 | 1195.6 | 831.7 | 1663.5 | 1245 |
| 50 | 300 | 175 | 648.8 | 1293.6 | 902.5 | 1805 | 1348.5 |
