U2 GRADE STUD LINK MARINE ANCHOR CHAIN/ Marine Chains

U2 GRADE STUD LINK MARINE ANCHOR CHAIN/ Marine Chains thumbnail-1
U2 GRADE STUD LINK MARINE ANCHOR CHAIN/ Marine Chains photo-1
US$ 1 - 1 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
TUF
Contact Supplier Request Quote Chat Now
Chongqing Perpetual Import And Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name TUF

Specifications

Anchor Chain:
1. High Strength Steel Bar.
2. Size: 12.5mm to 162mm.
3.U2 U3 RQ3 RQ4 Grade.
4. High Quality, Fast Deliv.

U2 GRADE STUD LINK MARINE ANCHOR CHAIN





1. Size from 12.5mm to 200mm ,we also can produce according to your requirement .



2.Material: alloy steel, generally including CM390, SM490, CM690, or aoording to your requirement



3.Grade :U1,U2&U3



4.Surface treatment: self color, black painted, zinc galvanized, hot dip galvanized or according to customer's requirement.



5.The tension beak load conforms to National Standard.



6. Studless anchor chains. Specification: 12.5-200mm, mainly adapt to vessels, fish net tenesmus, mine, municipal engineer, new established garden decoration





  ABS(America), LR(Britain), BV(France), GL(Germany), NK(Japan), KR(Korea), DNV(Norway), RINA(Italy),CCS(China).





Specification of Studless Link Anchor Chain:



Dia.
(mm) 		Outside Length
(mm) 		Outside Width
(mm) 		U2 U3 Weight
(KG/27.5M)
Proof Load
(KN) 		Breaking Load
(KN) 		Proof Load
(KN) 		Breaking Load
(KN)
16 96 56 66.2 132.3 92.42 184.83 138.14
17.5 105 61.25 78.89 157.78 110.55 221.1 165.8
19 114 66.5 93.6 187.2 130.32 260.64 194.9
20.5 123 71.8 108.64 217.27 151.7 303.42 227.13
22 132 77 125.4 250.9 174.4 349.4 262.29
24 144 84 149.9 298.9 207.9 415.8 312.26
26 156 91 175.4 350.8 244 488 366.76
28 168 98 203.8 406.7 283 566 423.36
30 180 105 234.2 467.5 324.9 649.8 486.85
32 192 112 265.6 531.2 369.6 739.3 554.7
34 204 119 299.9 599.8 417.3 834.6 628.08
36 216 126 336.1 672.3 467.8 935.7 701.54
38 228 133 374.4 748.7 521.3 1042.5 781.92
40 240 140 414.5 829.1 577.6 1155.2 861.17
42 252 147 457.7 915.3 636.8 1273.6 950.94
44 264 154 502.7 999.6 698.9 1398 1053
46 276 161 548.8 1097.6 763.9 1527.8 1142
48 288 168 597.8 1195.6 831.7 1663.5 1245
50 300 175 648.8 1293.6 902.5 1805 1348.5









U2 GRADE STUD LINK MARINE ANCHOR CHAIN/ marine chainsU2 GRADE STUD LINK MARINE ANCHOR CHAIN/ marine chains





U2 GRADE STUD LINK MARINE ANCHOR CHAIN/ marine chains
