Specifications
SS Honey extracting machine/commercial donut machine
1.SS raw material
2.honey processing machine
3. Certificate:ISO9001:2008
Honey Extraction Machine
Introduction of the honey extraction machine
1.This set of Equipment are made of 304 stainless steel, easy to operate, reliable, efficient, vacuum
suction honey.
2.They can achieve high vacuum and low concentration temperature is ideal for honey processing
equipment.
3.Apparatus comprising: a preheating tank, filter, concentrate tank, a condenser, a vacuum pump.
4.The honey thickener machine can reach high vacuity and lower thickening temperature.
After concentrating the materials will not change color, not change flavor, the quality of materials after concentrating will be very good.
5.Good designed of the structure make the machine small, low noise, easy to operate.
6. honey thickener vacuum concentrator to increase the concentration of honey.
Technical Data of the honey extraction machine
Item |
FR-50 |
FR-100 |
FR-200 |
FR-300 |
FR-500 |
Daily output(T) |
0.5 |
1 |
2 |
3 |
5 |
Heat supply |
Electrical steam |
Electrical steam |
Electrical steam |
Electrical steam |
Electrical steam |
Pump Motor |
1.5 KW 220/380V |
2.2 KW 380V |
4KW 380V |
4KW 380KW |
5.5KW 380V |
Motor power |
11 |
22 |
24 |
24 |
35 |
Concentration effect(kg) |
Increase 3.4Be per hour |
Increase 3.4Be per hour |
Increase 3.4Be per hour |
Increase 3.4Be per hour |
Increase 3.4Be per hour |
Weight(kg) |
160 |
220 |
360 |
400 |
500 |
Dimension(mm) |
1600*600*1600 |
1800*650*1800 |
2000*650*1800 |
2500*750*2000 |
3000*750*2000 |
