2015 Top Sale Security Mini Dome Onvif IP Camera

Name: 2015 Top Sale Security Mini Dome Onvif IP Camera
Brand: USCCTV
SKU: 133260147
Availability: InStock

Shenzhen USC Technology Co., Ltd.

US$ 17.7 - 21.7 MOQ: 5 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

USCCTV

Model Number:

USC-D2ANH2

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name USCCTV

Model Number USC-D2ANH2

Type IP Camera

Style Dome Camera

Sensor CMOS

Technology Infrared

Special Features Vandal-proof

2015 Top Sale Security Mini Dome Onvif IP Camera

1.H264,dual stream

2.Embedded RTOS

3. P2P function: plug and play

4.Mobile phone monitoring (iPhone, Windows Mobile, BlackBerry, Android)

5. IR - CUT automatically switch day and night

6. ONVIF, SDK

7. 24pcs infrared fine 5 LED light

8. Night vision:10-15M *lens:3.6mm / 6mm / 8mm for optional

Model		USC-D2ANH2
Camera	CPU	HS single chip SoC:build in(ARM9+DSP)high speed video processor
	Sensor	1/3″ 1.3Megapiexl low illumination scan cmos sensor
	Low illumination	Color:0.5Lux/F1.2, black/white:0.1Lux/F1.2(off),0Lux/F1.2(on)
	S/N	>60dB
	Shutter	1/5s-1/50,000s
	Socket	CS socket
	Lens	8mm/F1.2
	Day night	IR-CUT filter
Compression	Video compression	H.264/MJPEG
	Transit stream	64 Kbps~12Mbps,
	Audio compression	G.711
Image	Max size	1280x960P(30fps)
	Frame rate	30fps(1280x960) (960P)
		30fps(704x576)(D1)
		30fps(352x288))(CIF)
	Words overlay	Support channel name, date and time overlay, can change overlay position and color.
	Image set	Back-light compensation, brightness, contrast, saturation, auto gain, multi stream, frame rate can change from IE or Client
Network	Alarm	Motion detect, I/O alarm if network cut off
	Protocol	HTTP,DHCP,UDP,RTP/RTSP,NTP,FTP
	Internet	ONVIF,PSIA
	Common	No flicker, multi stream, user password, OSD
Socket	Audio in	One way (option)
	Audio out	One way (option)
	Communication	One RJ45 10M / 100M
	Alarm in	One way (option)
	Alarm out	One way (option)
	Wireless	Option
	Storage	SD card (option)
General	Temperature and Humidity	—10℃~+50℃,30%~90%RH
	Power	Support PoE(Option) or DC12V
	Supply	8W
	Size	140×140×140mm
	Weight	0.32kg
