Help CenterProfessional 16CH 1U H.265 PoE 4K NVR With 192Mbps Record Rate , Support P2P
Related Products
-
Professional 16CH 1.5U H.265 PoE 4K NVR With 256Mbps Bandwidth , Support P2PUS$ 338 - 365MOQ: 1 Piece -
Professional 32CH 2U H.265 PoE 4K NVR With 256Mbps Bandwidth , Support P2PUS$ 390 - 450MOQ: 1 Piece
-
Professional 32CH 2U H.265 RAID 4K NVR, Support P2PUS$ 405 - 450MOQ: 1 Piece
-
Professional 32CH 2U RAID H.265 PoE 4K NVR, Support P2PUS$ 527 - 585MOQ: 1 Piece
-
Professional 256CH 4U RAID Super NVR,Support Front LCD DisplayUS$ 3,420 - 3,705MOQ: 1 Piece
>H.265/H.264/MJPEG dual codec decoding
> Max 256Mbps incoming bandwidth
> Up to 8ch@1080P(4ch.H.265+4ch.H.264) realtime live-view
>Up to 12Mp resolution preview&playback
> HDMI/VGA simultaneous video output
> 8/16 channel synchronous realtime playback, GRID interface
> Support Multi-brand network cameras:Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus,
Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek and etc.
> ONVIF Version 2.4 conformance
> 3D intelligent positioning with Dahua PTZ camera
> Support 2 SATA HDDs up to 12TB, 2 USB(1 USB3.0)
> Support IPC UPnP, 8PoE ports
>Support P2P, QR code scan & add
> Multiple network monitoring: Web viewer, CMS(DSS/Smart PSS) & Smart Phone(DMSS)
Model |
NVR-9416AE-P8 |
System | |
Main Processor |
Dual-core embedded processor |
Operating System |
Embedded LINUX |
Video& Audio | |
IP Camera Input |
16 channel |
Two-way Talk |
1channel Input, 1channel Output, RCA |
Display | |
Interface |
1 HDMI , 1 VGA |
Resolution |
3840×2160, 1920×1080, 1280×1024, 1280×720, 1024×768 |
Display Split |
1/4/8/9/16 |
OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
Recording | |
Compression |
H.265/H.264/MJPEG |
Resolution |
12Mp, 8Mp, 6Mp, 5Mp, 3Mp, 1080P, 1.3Mp, 720P & etc. |
Record Rate |
192Mbps |
Bit Rate |
1~ 20Mbps |
Record Mode |
Manual, Schedule(Regular(Continuous), MD, Alarm), Stop |
Record Interval |
1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
Video Detection & Alarm | |
Trigger Events |
Recording, PTZ, Tour, Alarm out, Video Push, Email, FTP, Snapshot, Buzzer & Screen tips |
Video Detection |
Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank |
Alarm Input |
8 channel |
Relay Output |
3 channel |
Playback & Backup | |
Sync Playback |
1/4/9/16 |
Search Mode |
Time/Date, Alarm, MD & Exact search (accurate to second), Smart search |
Playback Function |
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
Backup Mode |
USB Device/Network/Internal SATA burner |
Network | |
Ethernet |
1 RJ-45 port (10/100/1000Mbps) |
PoE |
8 ports (IEEE802.3at/af) |
Network Function |
HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, IP Search(Support Dahua IP camera, DVR, NVS and etc.) |
Max. User Access |
128 users |
Smart Phone |
iPhone, iPad, Android, Windows Phone |
Storage | |
Internal HDD |
2 SATA III ports, up to 12TB |
Auxiliary Interface | |
USB |
2 ports (1 Rear USB3.0, 1 Front USB2.0) |
RS232 |
1 port, For PC communication& Keyboard |
RS485 |
1 port, For PTZ control |
General | |
Power Supply |
Single, AC 100~240V, 50/60 Hz |
Power Consumption |
Max 25.5W for single port,120W in total |
Working Environment |
-10°C~+55°C/10%~90%RH/86~106kpa |
Dimension |
1U, 375mm×327mm×53mm |
Weight |
2.65KG(without HDD) |
Headquartered in Hangzhou (China), and sales & support office in Dallas (United States), Linovision is committed to be a leading integrated surveillance solutions provider. From 2007,Linovision started developing PC based DVR/NVR software for Hikvision & Dahua DVR cards, then their IPcameras, and become software partner of leading manufacturers.
We are proud of supplying a complete line of professional IP video surveillance products in affordable price, by working closely with top level manufacturers in China. And with continuous investment in the latest technologies, we can also provide comprehensive system integration service.
Moreover, we are also developing cloud based video management solution for the next generation of video surveillance system.
Our Mission: To be a global leading integrated video surveillance solutions provider.
Our Advantage
- Consulting and Systems designing
- Product qualification and recommendation
- Project Integration service
- End to End & One stop sourcing
- Help to make website and marketing material
- OEM hardware/software design for specific needs
- Life cycle support
- Regularly training and knowledge updates
Our Milestone
| Year | Exhibition Name | Address | Year | Exhibition Name | Address |
| 2011 | Public Security Exhibition | Shenzhen, China | 2012 | ISC WEST 2012 Exhibition | Las Vegas, USA |
| 2013 | ISC WEST 2013 Exhibition | Las Vegas, USA | 2013 | EXPOSEC Exhibition | Sao Paolo, Brazil |
| 2014 | ISC WEST 2014 Exhibition | Las Vegas, USA | 2014 | EXPOSEC Exhibition | Sao Paolo, Brazil |
| 2014 | Security Essen Exhibition | Essen, Germany | 2015 | ISC WEST 2015 Exhibition | Las Vegas, USA |
| 2015 | EXPOSEC Exhibition | Sao Paolo, Brazil | 2016 | ISC WEST 2016 Exhibition | Las Vegas, USA |
Q. May I print our company logo on camera and NVR?
A: Of course, buyer logo is welcome in our company.
We have one production line for printing buyer logo.
Q. Do you provide warranty for your products?
A: Yes, we promise 2 years warranty for all our products.
Q.What is your method of payment?
A: Pay via T/T, Western Union, Paypal, Escrow is welcome.
Q.What is Minimum Order Quantity?
A: Sample order is welcome, but the price is depend on the quantity.
Q: How to ship the goods?
A: For small parcels, we recommend to use the express, such as Fedex, DHL, TNT, UPS etc. For big order, we also have cooperated forwarders.
